CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Wireless AC1200 Dual-band Router Model Name F1200 Brand Name Tenda Applicant SHENZHEN TENDA TECHNOLOGY CO.,LTD Address 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen,China.518052 Standard(s) FCC Part 15, Subpart B:2013 ANSI C63.4 -2009 Report(s) NEI-FCCE-1-1406C099 The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

RV-0000000 Project No.: 1406C099 Page 2 of 1 0 RV-0000000 Project No.: 1406C099 Page 3 of 1 0 RV-0000000 Project No.: 1406C099 Page 4 of 1 0 RV-0000000 Project No.: 1406C099 Page 5 of 1 0

Label location

RV-0000000 Project No.: 1406C099 Page 6 of 1 0 RV-0000000 Project No.: 1406C099 Page 7 of 1 0 Antenna RV-0000000 Project No.: 1406C099 Page 8 of 1 0 RV-0000000 Project No.: 1406C099 Page 9 of 1 0 RV-0000000 Project No.: 1406C099 Page 10 of 1 0

Page 1 of 7 FCC RF EXPOSURE REPORT FCC ID: V7TF1200 Project No. : 1406C099 Equipment : Wireless AC1200 Dual-band Router Model : F1200 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Page 2 of 7 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. BrandModel NameAntenna TypeConnector Gain(dBi) 0 Q5115 Internal N/A 3.25 1 Q5115 Internal N/A 3.25 Page 3 of 7 TEST RESULTS EUT： Wireless AC1200 Dual-band Router Model Name : F1200 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX A MODE / CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.25 2.1135 10.1 10.2329 0.004304771 Complies 3.25 2.1135 9.8 9.5499 0.004017451 Complies 3.25 2.1135 12.7 18.6209 0.007833401 Complies EUT： Wireless AC1200 Dual-band Router Model Name : F1200 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N20 MODE_Total / CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.25 2.1135 12.78 18.9671 0.007979031 Complies 3.25 2.1135 12.81 19.0985 0.008034341 Complies 3.25 2.1135 15.71 37.2392 0.015665721 Complies Page 4 of 7 EUT： Wireless AC1200 Dual-band Router Model Name : F1200 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N40 MODE_ Total /CH38, CH46 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.25 2.1135 14.05 25.4097 0.010689331 Complies 3.25 2.1135 14.31 26.9774 0.011348811 Complies EUT： Wireless AC1200 Dual-band Router Model Name : F1200 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX AC N20 MODE_Total /CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.25 2.1135 14.71 29.5801 0.012443721 Complies 3.25 2.1135 14.51 28.2488 0.011883661 Complies 3.25 2.1135 14.51 28.2488 0.011883661 Complies Page 5 of 7 EUT： Wireless AC1200 Dual-band Router Model Name : F1200 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX AC N40 MODE_ Total /CH38, CH46 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.25 2.1135 16.9 48.9779 0.020603941 Complies 3.25 2.1135 16.8 47.8630 0.020134941 Complies EUT： Wireless AC1200 Dual-band Router Model Name : F1200 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX AC N80 MODE_Total /CH44 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.25 2.1135 13.6 22.9087 0.009637191 Complies Note: the calculated distance is 20 cm.

Report No. : : NEI-FCCP- This repo P E M A A Te D D I s Te T e A 2-1406C09 9 FCC rt concerns roject No. quipment Model Name Applicant Address ested by: B ate of Rece ate of Test ssued Date esting Eng echnical M Authorized S N TEL: 0 9 C Rad FCC I s (check o : 14 0 : Wi e : F1 : S H CO : 6- 8 Zh Sh BTL Inc. EM eipt: Jun. 1 t: Jun. 16, 2 : Jul. 07, 20 gineer Manager Signatory B No.3, Jinsh Dalang To 0769-8318- dio Te ID: V7T ne) : O 06C099 reless AC1 2 200 HENZHEN T O.,LTD 8 Floor, Tow ongshanyu enzhen,Ch MC Laborato 6, 2014 2014 ~ Jul. 0 014 : : : BTL IN hagang 1st own, Dong -3000 FA est Re TF120 riginal Gra 200 Dual-ba TENDA TEC wer E3, No. an Road, N ina.518052 ory 07, 2014 (David (Leo H (Steven NC. t Road, Sh gguan, Chin AX: 0769-8 eport 00 ant Cla and Router CHNOLOGY 1001, Nanshan Dis 2 Mao) ung) n Lu) ixia, na. 8319-6000 Pa t ass II Chan r Y strict, ge 1 of 162 nge Report No.: NEI-FCCP-2-1406C099 Page 2 of 162 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-2-1406C099 Page 3 of 162 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 DESCRIPTION OF SUPPORT UNITS 15 4 . EMC EMISSION TEST 16 4.1 CONDUCTED EMISSION MEASUREMENT 16 4.1.1 POWER LINE CONDUCTED EMISSION 16 4.1.2 TEST PROCEDURE 16 4.1.3 DEVIATION FROM TEST STANDARD 16 4.1.4 TEST SETUP 17 4.1.5 EUT OPERATING CONDITIONS 17 4.1.6 EUT TEST CONDITIONS 17 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 TEST PROCEDURE 19 4.2.3 DEVIATION FROM TEST STANDARD 19 4.2.4 TEST SETUP 19 4.2.5 EUT OPERATING CONDITIONS 20 4.2.6 EUT TEST CONDITIONS 20 4.2.7 TEST RESULTS (9K TO 30MHz) 21 4.2.8 TEST RESULTS (BETWEEN 30 TO 1000 MHz) 21 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 21 5 . 26dB SPECTRUM BANDWIDTH 22 5.1 APPLIED PROCEDURES / LIMIT 22 5.1.1 TEST PROCEDURE 22 5.1.2 DEVIATION FROM STANDARD 22 5.1.3 TEST SETUP 22 5.1.4 EUT OPERATION CONDITIONS 22 5.1.5 EUT TEST CONDITIONS 22 5.1.6 TEST RESULTS 22 Report No.: NEI-FCCP-2-1406C099 Page 4 of 162 Table of Contents Page 6 . MAXIMUM CONDUCTED OUTPUT POWER 23 6.1 APPLIED PROCEDURES / LIMIT 23 6.1.1 TEST PROCEDURE 23 6.1.2 DEVIATION FROM STANDARD 24 6.1.3 TEST SETUP 24 6.1.4 EUT OPERATION CONDITIONS 24 6.1.5 EUT TEST CONDITIONS 24 6.1.6 TEST RESULTS 24 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 25 7.1 APPLIED PROCEDURES / LIMIT 25 7.1.1 TEST PROCEDURE 25 7.1.2 DEVIATION FROM STANDARD 25 7.1.3 TEST SETUP 25 7.1.4 EUT OPERATION CONDITIONS 25 7.1.5 EUT TEST CONDITIONS 25 7.1.6 TEST RESULTS 25 8 . POWER SPECTRAL DENSITY TEST 26 8.1 APPLIED PROCEDURES / LIMIT 26 8.1.1 TEST PROCEDURE 26 8.1.2 DEVIATION FROM STANDARD 26 8.1.3 TEST SETUP 26 8.1.4 EUT OPERATION CONDITIONS 26 8.1.5 EUT TEST CONDITIONS 26 8.1.6 TEST RESULTS 26 9 . FREQUENCY STABILITY MEASUREMENT 27 9.1 APPLIED PROCEDURES / LIMIT 27 9.1.1 TEST PROCEDURE 27 9.1.2 DEVIATION FROM STANDARD 27 9.1.3 TEST SETUP 28 9.1.4 EUT OPERATION CONDITIONS 28 9.1.5 EUT TEST CONDITIONS 28 9.1.6 TEST RESULTS 28 10 . MEASUREMENT INSTRUMENTS LIST 29 11 . EUT TEST PHOTOS 31 ATTACHMENT A - CONDUCTED EMISSION 35 ATTACHMENT B - RADIATED EMISSION (9KHZ to 30MHZ) 38 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 40 Report No.: NEI-FCCP-2-1406C099 Page 5 of 162 Table of Contents Page ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 47 ATTACHMENT E – 26DB BANDWIDTH 104 ATTACHMENT F - MAXIMUM OUTPUT POWER 121 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 128 ATTACHMENT H - POWER SPECTRAL DENSITY 140 ATTACHMENT I – FREQUENCY STABILITY 161 Report No.: NEI-FCCP-2-1406C099 Page 6 of 162 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-2-1406C099 Original Issue. Jul. 07, 2014 Report No.: NEI-FCCP-2-1406C099 Page 7 of 162 1. CERTIFICATION Equipment : Wireless AC1200 Dual-band Router Brand Name : Tenda Model Name : F1200 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor,Tower E3,No.1001,Zhongshanyuan Road,Nanshan District, Shenzhen,China.518052 Date of Test : Jun. 16, 2014 ~ Jul. 07, 2014 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart E(15.407) / ANSI C63.4 : 2009 FCC KDB 789033 D01 General UNII Test Procedures v01r03 . The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. EMC Laboratory. The test data,…

Text truncated - open the document above for the full version.

Report No.: NEI-FCCP-2-1406C099 Page 76 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX N40 Mode 5230MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 77 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX N40 Mode 5230MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 78 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX N40 Mode 5230MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 79 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX N40 Mode 5230MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 80 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5180MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 81 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5180MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 82 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5180MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 83 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5180MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 84 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5200MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 85 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5200MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 86 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5200MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 87 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5200MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 88 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5240MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 89 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5240MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 90 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5240MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 91 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N20 Mode 5240MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 92 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5190MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 93 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5190MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 94 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5190MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 95 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5190MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 96 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5230MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 97 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5230MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 98 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5230MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 99 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5230MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 100 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N80 Mode 5210MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 101 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5210MHz Vertical Report No.: NEI-FCCP-2-1406C099 Page 102 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5210MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 103 of 162 Orthogonal Axis : X Test Mode : Band 1/ TX AC N40 Mode 5210MHz Horizontal Report No.: NEI-FCCP-2-1406C099 Page 104 of 162 ATTACHMENT E – 26DB BANDWIDTH Report No.: NEI-FCCP-2-1406C099 Page 105 of 162 Test Mode : Band 1/TX A Mode_CH36/CH40/CH48 TX CH36 Report No.: NEI-FCCP-2-1406C099 Page 106 of 162 TX CH40 TX CH48 Report No.: NEI-FCCP-2-1406C099 Page 107 of 162 Test Mode : Band 1/TX N20 Mode_CH36/CH40/CH48_ANT2 TX CH36 Report No.: NEI-FCCP-2-1406C099 Page 108 of 162 TX CH40 TX CH48 Report No.: NEI-FCCP-2-1406C099 Page 109 of 162 Test Mode : Band 1/TX N20 Mode_CH36/CH40/CH48_ANT3 TX CH36 Report No.: NEI-FCCP-2-1406C099 Page 110 of 162 TX CH40 TX CH48 Report No.: NEI-FCCP-2-1406C099 Page 111 of 162 Test Mode : Band 1/TX N40 Mode_CH38/CH46_ANT2 TX CH38 TX CH46 Report No.: NEI-FCCP-2-1406C099 Page 112 of 162 Test Mode : Band 1/TX N40 Mode_CH38/CH46_ANT3 TX CH38 TX CH46 Report No.: NEI-FCCP-2-1406C099 Page 113 of 162 Test Mode : Band 1/TX AC N20 Mode_CH36/CH40/CH48_ANT2 TX CH36 Report No.: NEI-FCCP-2-1406C099 Page 114 of 162 TX CH40 TX CH48 Report No.: NEI-FCCP-2-1406C099 Page 115 of 162 Test Mode : Band 1/TX AC N20 Mode_CH36/CH40/CH48_ANT3 TX CH36 Report No.: NEI-FCCP-2-1406C099 Page 116 of 162 TX CH40 TX CH48 Report No.: NEI-FCCP-2-1406C099 Page 117 of 162 Test Mode : Band 1/TX AC N40 Mode_CH38/CH46_ANT2 TX CH38 TX CH46 Report No.: NEI-FCCP-2-1406C099 Page 118 of 162 Test Mode : Band 1/TX AC N40 Mode_CH38/CH46_ANT3 TX CH38 TX CH46 Report No.: NEI-FCCP-2-1406C099 Page 119 of 162 Test Mode : Band 1/TX AC N80 Mode_CH44 _ANT2 TX CH44 Report No.: NEI-FCCP-2-1406C099 Page 120 of 162 Test Mode : Band 1/TX AC N80 Mode_CH44 _ANT3 TX CH44 Report No.: NEI-FCCP-2-1406C099 Page 121 of 162 ATTACHMENT F - MAXIMUM OUTPUT POWER Report No.: NEI-FCCP-2-1406C099 Page 122 of 162 Test Mode :Band 1/TX A Mode Test Channel Frequency (MHz) Conducted Output Power (dBm) LIMIT (dBm) LIMIT (W) CH36 5180 10.10 30.00 1.0000 CH40 5200 9.80 30.00 1.0000 CH48 5240 12.70 30.00 1.0000 Report No.: NEI-FCCP-2-1406C099 Page 123 of 162 Test Mode :Band 1/TX N20 Mode-ANT 2 Test Channel Frequency (MHz) Conducted Output Power (dBm) LIMIT (dBm) LIMIT (W) CH36 5180 8.90 30.00 1.0000 CH40 5200 9.10 30.00 1.0000 CH48 5240 12.00 30.00 1.0000 Test Mode :Band 1/TX N20 Mode-ANT 3 Test Channel Frequency (MHz) Conducted Output Power (dBm) LIMIT (dBm) LIMIT (W) CH36 5180 10.50 30.00 1.0000 CH40 5200 10.40 30.00 1.0000 CH48 5240 13.30 30.00 1.0000 Test Mode :Band 1/TX N20 Mode-Total Test Channel Frequency (MHz) Conducted Output Power (dBm) LIMIT (dBm) LIMIT (W) CH36 5180 12.78 30.00 1.0000 CH40 5200 12.81 30.00 1.0000 CH48 5240 15.71 30.00 1.0000 Report No.: NEI-FCCP-2-1406C099 Page 124 of 162 Test Mode : Band 1/TX N40 Mode-ANT 2 Te…

Text truncated - open the document above for the full version.

Report No.: NEI-FCCP-1-1406C099 Page 27 of 148 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: NEI-FCCP-1-1406C099 Page 28 of 148 Radiated Measurement Photos 9KHz to 30MHz Report No.: NEI-FCCP-1-1406C099 Page 29 of 148 Radiated Measurement Photos 30MHz to 1000MHz Report No.: NEI-FCCP-1-1406C099 Page 30 of 148 Radiated Measurement Photos Above 1000MHz
