55 44 33 22 11 D D C C B B A A TENDA Block Diagram TENDA LAN3 PQWER/SYS 2.4G 5G RJ451X1WAN蓝色 WAN LAN2 IPTV Reset&WPSButton DC12V/2APower IN LANRJ451X3黄色 LAN1 USB IPTVRJ45 PWR 3 Inner 2 Traces 4 Bottom GND 2 Traces Top Inner 1 1 3. PCB Interface Definition 2. PCB Layer Definition 1 Block Diagram USB2.0 FR9886 Step-DownRegulator DC 5V/1ADC 3.3V/4A DC1.25V/3.5A GSS5509A Inter Regulator+ MOS +Inductance DC 2.5V Inter Regulator+ PNPB772 DC 3.3V DC 3.3V Inter POROptionReset Reset DDR232Mx16bit SPI SPIFLASH8MB20MHzXTAL 20MHzXTAL HSIC SPDT Switch Inter PA0 TX Out Inter PA0 TX Out DC 1.25V 5GHz TX0 DC 3.3V 5GHz RX1 SPDT Switch 5GHz RX0 Antenna 1Connector Diplexer Diplexer Antenna 0Connector Inter PA0 TX Out SPDT Switch 2.4GHz TX12.4GHz TX02.4GHz RX1 Inter PA1 TX Out 2.4GHz RX0 SPDT Switch 5GHz TX1 USB Interface MIC2025 USB2.0 BCM53125S DC 5V/1A DC 3.3V DC1.20V Inter Regulator+ MOS +Inductance DC 3.3V 2 1X2 Transformer WAN LAN1~4 BCM47186 RGMII DC 12V/2A FR9808 Step-DownRegulator W9751G6JBMX25L6406E BCM43236 GW2168 GW2168 AS179 AS179 DP2012 DP2012 G3601DG G1801DG 1 Transforner GSS5509A 25MHzXTAL 待定 DC 1.8V DC 3.3VDC 1.8V FS1117 LDO DC 3.3V DC 1.8V WPS DC 3.3V N60 TitleSize Document Number Rev Date: Sheet of Block Diagram 1.0 N60 C 418 Wednesday, April 25, 2012 TitleSize Document Number Rev Date: Sheet of Block Diagram 1.0 N60 C 418 Wednesday, April 25, 2012 TitleSize Document Number Rev Date: Sheet of Block Diagram 1.0 N60 C 418 Wednesday, April 25, 2012

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT –All View EUT –Top View EUT – Bottom View EUT – Right Side View EUT – Left Side View EUT – Adapter View EUT – Adapter Label View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label Here

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT –Uncover View EUT –PCB Top View EUT –PCB Bottom View EUT –PCB Top Shielding Off View

Circuit Description • N60 program. Power adapter in part by the 9V1.0Ah driven by the conversion of the 5V and 3.3V and 1.8V switching power supply chip to the minimum system power supply. The main chip BCM47186 Integrated IEEE 802.11n radio, media access controller (MAC), baseband, CPU, memory controller and 5‐port Fast Ethernet switch ;Integrated 2.4 GHz power amplifier that has been proved in the field on shipping production platforms ;USB 2.0 host port for storage and print server applications ;New applications and services support through NAND Flash and I2S ;PCM interface support utilizing Broadcom's proven VoIP software stack.BCM43236 Integrated dual 2.4 GHz and 5.0 GHz power amplifiers provide a path to lower‐cost WLAN solutions. The BCM53125 is integrated multilayer switch to support the IEEE 802.3az specification for EEE.
