V7TRX27PAX5700 Tri-Band Gibabit Wi-Fi 6E Router

SHENZHEN TENDA TECHNOLOGY CO., LTD.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Feb 05, 2023
Application Purpose: Original Equipment
Date of Application: Dec 29, 2022
Equipment Note: AX5700 Tri-Band Gibabit Wi-Fi 6E Router
Frequency Range: 5250.00000000 - 5250.00000000
Company: SHENZHEN TENDA TECHNOLOGY CO., LTD.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

II. Connect the router to the internetLED indicators&Jack, ports and buttonsI. Connect the router Scenario1: Set up the device as a router Method 2: Setup through web UI The "new router" and "router" in this guide refer to the router in the package. Step 1: Import your PPPoE user name and password into the new router (Optional) 1. Power on your original and new routers. 2. Connect the WAN port of the original router to a LAN port (1, 2 or IPTV/3) of the router using an Ethernet cable. After the LED indicator of the new router blinks fast for 8 seconds, the PPPoE user name and password are imported to your new router. 3. Remove the original router. 1. Connect the client to the router. Method 1: Connect the wireless client such as a mobile phone to the WiFi network of the router. The SSID and password can be found on the bottom label of the device. Method 2: Use an Ethernet cable to connect the computer to the 1, 2 or IPTV/3 port of the router. 3. The router detects your connection type automatically. − If you have imported your PPPoE user name and password into the router, click Next. − If you did not import your PPPoE user name and password into the router, select the ISP Type based on your region and ISP and enter required parameters (if any). Then, click Next. 4. Set the WiFi name, WiFi password and login password for the router. Click Next. To access the internet with: - Wired devices: Connect to the LAN port of your router. - Wireless devices: Connect to your WiFi network using the WiFi name and password you set. 2. Start a browser on the client (computer used as an example) and enter tendawifi.com in the address bar to access the web UI. Then, click Start Now. After the router is powered on for about 40 seconds, the system completes startup. The status of the LED indicator is shown in the following table. Node Type Primary node Secondary node LED indicator Status Description Solid green Solid green Blinking green slowly Blinking green fast for 2 minutes Blinking red slowly The router is not connected to the internet. The router is pending for or performing WPS negotiation or Mesh networking. The router failed to connect to the internet. Networking succeeds. Good connection quality. Solid yellow Networking succeeds. Fair connection quality. Solid redNetworking succeeds. Poor connection quality. Blinking green fast The router is networking with another node. Blinking red slowly The router failed to connect the internet or network with another node. The system is starting up, or the router is already connected to the internet. Done. • To access the internet with: - Wired devices: Connect to the LAN port of your router. - Wireless devices: Connect to your WiFi network using the WiFi name and password you set. • If you want to manage the network remotely, tap on the App home page and use your account to log in. Tips This function is only applicable when the connection type of the original router is PPPoE, except for PPPoE of some special ISPs or PPPoE connection set up manually with VLAN information. Description Jack/Port/ Button Power jack. Please use the included power adapter to connect this jack to a power source for power supply. Reset button. When the router is working normally, hold the button down using a needle-like item (such as a pin) for about 8 seconds, and then release it when the LED indicator blinks red fast. The router is reset. 10/100/1000 Mbps auto-negotiation WAN port. Used to connect to a modem or the Ethernet jack using an Ethernet cable for internet access. 10/100/1000 Mbps auto-negotiation LAN port. Used to connect to computers, switches or game machines, etc. POWER WPS Reset 1, 2 10/100/1000 Mbps auto-negotiation LAN/IPTV port. It is a LAN port by default. When the IPTV function is enabled, it can only serve as an IPTV port to connect to a set-top box. IPTV/3 WPS/Mesh button. • WPS: When it is used as a WPS negotiation button, you can connect to the WiFi network of the router without entering the WiFi password. Method: Short press the button (for about 1 second), and the LED indicator blinks fast. Within 2 minutes, enable the WPS function of the other WPS-supported device to establish a WPS connection. • Mesh: When it is used as a Mesh networking button, you can extend your network with another device that supports the Mesh function. Method: Press this button for about 3 seconds. The LED indicator blinks green fast, which indicates the device is searching for another device to form a network. Within 2 minutes, press the MESH/WPS button of another device for 1 to 3 seconds to negotiate with this device. WAN AX5700 Tri-Band Gigabit Wi-Fi 6E Router RX27 Pro/TX27 Pro Quick Installation Guide • Wireless router x 1 • Power adapter x 1 • Ethernet cable x 1 • Quick installation guide x 1 Package contents Please read this guide before you start with the quick setup upon the first use. This guide instructs how to install and connect the device. For more information such as the description of symbols displayed on relevant materials, please visit www.tendacn.com. 1. Ensure that the router is powered on. 2. Connect the WAN port of the router to the LAN port of your modem or the Ethernet jack using an Ethernet cable. 1. Download the Tenda WiFi App onto your mobile device by scanning the QR code or searching for Tenda WiFi in Google Play or App Store. Then install the Tenda WiFi App. 2. Connect the mobile phone to the WiFi network of the router. The SSID and password can be found on the bottom label of the router. 3. Run the Tenda WiFi App and follow the onscreen instructions to connect the router to the internet. After the router is connected to the internet, its LED indicator lights solid green. Step 2: Connect the WAN port of the routerMethod 1: Setup through Tenda WiFi App Note If you use the modem for internet access, please power off the modem first before connecting the WAN port of the router to the LAN port of your modem. Tenda WiFi Tenda_XXXXXX Settings Tips If you can…

Text truncated - open the document above for the full version.

Attestation Statements

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

Attestation Statements

(SHENZHEN TENDA TECHNOLOGY CO., LTD.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 27-02-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: V7TRX27P SHENZHEN TENDA TECHNOLOGY CO., LTD. (“the applicant”) certifies that, as of the date of the filing of the application, Tenda Technology, Inc is our designated U.S. agent for service of process for the above referenced FCC ID. SHENZHEN TENDA TECHNOLOGY CO., LTD. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Tenda Technology, Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Tenda Technology, Inc FRN: 0033410028 Address: 18557 Gale Ave, City of Industry, CA 91748, United States Contact Person: Will Wang Email: [email protected] Job title: General Manager Sincerely, [SHENZHEN TENDA TECHNOLOGY CO., LTD. Tenda Technology, Inc Shen Yue Will Wang [Insert Applicant signature] [U.S. Agent signature] Rev 1/26/2023

Cover Letter(s)

!"#$"#%#%#&"'(')*&'+,(%+ --.. /012,%3#4,+5665,$7.89-,.., &8 ! &8 & 9: .;7 <.+9.( 7&:8 =%(>+ --.. +4?.775.9-,!@,7%3 &8 7) &8 & . -::8&-.77--.37:-A.B, -7C4 5A.B D--. : EFC66%0=-)GG02/#9 %8:-.7 9EHCD,%EHCD %-I %- 2&&> JC%9EHCD G + H6HH05H0HC &8 ! !* 2 #7 !7 K KKKKKKKKK+ LMNOPQ RSTQUOVW XYOZ[MY\]]^__`Xa^NXMb cdefghigjjklmnolpqlrqsitulqqjhvqwhxuqiyhilrqtnlrhikzqvt{qul|

Cover Letter(s)

! "#$"%&'()&'(*'(+,*'-&(./.01-.23/*+2 4 56789::;3*:<=;'>3(:2?@@?3)A:BCDAEBFGEB H:EI3(EBDAEB+JDK;JLK3 $%A=BMA=B $-AJBE *:N* =9=OJLEKJ:BP2QR+=SK28--*-P 'IJD:BDK;EEK?T, 5U@TVW)'Q'(,,H *A=(=KA=;9EBID %GXY=L KN $QZ*H[TZV H=O=;= BL=BG\X=;N]]]]]] ^_ ?2/:BC 6*=;\-:BOJI=BKJE9JKF `ab R`cdefdgehi g$ " i h!" g" ## ## _d e j _ k! " l# # bi" ! " ^# 4g " # # $ i " hiih " $g ! " "# `a R`adedeR #g $# i "#$ " i # g "# i "# m g "# R T2%A:; K6*=;\-:BOJI=BKJE9JKFn%*-o g 4`pqrstuvwxytzz{||{t}~|t{{}txvttz{vwvwxzxv{} ! `aR i"# `aR`## i g$ bi ^ " " i h!" de i |x~|}^ b # i i T@TT6?T6TZ" ! ## %A=B1G= ¡¢£¤¥¦§ ¡¢£¡ ̈¥© ̈ª«¬¥¦§¡§ ̈¥® ̄©¤°±¤£¡§ ̈¥¦¤¡¦§¤²³ ̈¥§¤£ ̈§ ́¤ ̈μ¡ ̈¶ £ ̈¶·£ ̧ ̈£¹º ̈¥£ ̈¶»® ±© ¦ ̈ ̈©¢ ̈ ©¼½¾· ̈¦¦¡ ̈§¤£» ·½¿¿£¢§¤£ ©£ ̈¤À ́ ́ ̈¤¤» ²¼ ̈ ̈À¦ ̈¡ ̈¢£ ̈¡ ̈¥©¢¶£¢¤Á¢ £»±§¡ ̈ ¤£ ¥¢§©® ³¼Á¢§¤¶¤§¤¤ ̈£¢¤¡ª ¥±§¡ ̈ ̈ ̈¾ ̈¥§¤ ̈§ ̈¡¢ ̈£ ̈¤À ́¤§¤ ¶¦¤ ̈§©±¿¦¤

Cover Letter(s)

!"#$%$$&'$&$( )"*!+",-. "/012-".3456 -7 89:;< 9=>?@AB?@AC@ADC@E?AFGFHIEFJ*GCJ KK=L&MNO44/*C4P"/@Q*A4J'%%'*B+4-20+ -7, -R4 .*A -0+ -10!/13!* >+"-S+"-*E+1- JT'M%T$ "3O /"!+ !# UVK:=DWT(%%C/1&X -.H1Y Y1!)1&N1L@R4,!"/ Z;:K[=RW$(\/4*CW$(\/4 ]=C"-. ^88_=`(CRW$(\ abcdefgchiejklmdnoephqirsihetukrmvikikwkik&gxtyezuekrvej{b|}~baankphqir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

Cover Letter(s)

!"!!#$!#!% &'()*+ ,-./*+0123*4 56789 6:;<=>?<=>@=>A@=B<>CDCEFBCG'D@G HIIJJ:K#LMN11,'@1O,=P'>1G$""$'?(1*/-(*4)*Q1+'>*-(*.-,.0' ;(*R(*'B(.*GS$L"S! 0N,( TIUIJ7:AVS%""@,.#W*+E.XX.&.#M.K=Q1), Y87IJZ:QV!%[,1'@V!%[,1 \I:@*+ ]55^:_%@QV!%[ `JIab`\IZIcJ`6IJd776I7`]efI I67 8]edUgY`dU8d`\IZ6IJJ7dIhigjklmnI `cJ` 6IJaII`]eJ7f87d6ZJJJ7d6 `o 8d`I87Jg pq41)(r *4s)-.1*-,/,+.*/()(1,.R.1*'3N-+1*1(-.101*0)-' (*t41)u ;.*0,N4' ;./*), v vvvvvvvvvvvvvvvvvvvvvvv >2 ;(*F) @N LK#%SS#!%KS%"wL =2.N 0,x*+G0*

Cover Letter(s)

TP-Link Corporation Limited Declaration of Frequency Stability We [TP-Link Corporation Limited] ensure that the product meets e-CFR Title 47 section 15.407(g) and KDB 789033 D02v02r01 frequency stability such that the emissions are maintained within the band of operation under all conditions of normal operation as specified in the user's manual. Sincerely Yours, Print Name: Sarah Wang Title: Regulatory Compliance Manager Company Name: TP-Link Corporation Limited Tel: 00852-37585503 Email: [email protected]

External Photos

Project No.: 022022-5924 Page 1 of 5 ATTACHMENT PHOTOGRAPHS OF EUT Project No: 022022-5923 Equipment: AX5700 Tri-Band Gibabit Wi-Fi 6E Router Model: RX27 Pro FCC ID: V7TRX27P Project No.: 022022-5924 Page 2 of 5 Project No.: 022022-5924 Page 3 of 5 Project No.: 022022-5924 Page 4 of 5 Project No.: 022022-5924 Page 5 of 5

ID Label/Location Info

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. www.tendacn.com Made in China Serial No. SSID Pin No. MAC AX5700 Tri-Band Gigabit Wi-Fi 6E Router Model: RX27 Pro IP Address: 192.168.0.1 Input: 12V 2A FCC ID: V7TRX27P XXXXXX_XXXXXX XXXXXXXXXXXXXX XXXXXXXXXXXX XXXXXXXX Indoor Use only This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. www.tendacn.com Made in China Serial No. SSID Pin No. MAC AX5700 Tri-Band Gigabit Wi-Fi 6E Router Model: TX27 Pro IP Address: 192.168.0.1 Input: 12V 2A FCC ID: V7TRX27P XXXXXX_XXXXXX XXXXXXXXXXXXXX XXXXXXXXXXXX XXXXXXXX Indoor Use only

Internal Photos

Project No.: 022022-5924 Page 1 of 6 ATTACHMENT PHOTOGRAPHS OF EUT Project No: 022022-5923 Equipment: AX5700 Tri-Band Gibabit Wi-Fi 6E Router Model: RX27 Pro FCC ID: V7TRX27P Project No.: 022022-5924 Page 2 of 6 2.4G+5G Ant. 1 2.4G+5G Ant. 2 2.4G Ant. 3 6G Ant. 1 6G Ant. 2 Project No.: 022022-5924 Page 3 of 6 Project No.: 022022-5924 Page 4 of 6 Project No.: 022022-5924 Page 5 of 6 Project No.: 022022-5924 Page 6 of 6

RF Exposure Info

Report No.: FCC022022-5923RF14 Page 1 of 8 Product Name: AX5700 Tri-Band Gibabit Wi-Fi 6E Router Report No: FCC022022-5924RF14 Product Model: RX27 Pro; RX27 Pro Security Classification: Open Version: V1.0 Total Page: 8 TIRT Testing Report Prepared By: Checked By: Approved By: Stone Tang Randy Lv Daniel Chen Report No.: FCC022022-5923RF14 Page 2 of 8 FCC RF EXPOSURE REPORT FCC ID: 2A9M7AP3220L Project No. : 022022-5924 Equipment : AX5700 Tri-Band Gibabit Wi-Fi 6E Router Brand Name : Tenda Test Model : RX27 Pro Series Model : TX27 Pro Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Aug. 12, 2022 Date of Test : Aug. 12, 2022~Sep. 30, 2022 Issued Date : Dec. 23, 2022 Report Version : V1.0 Test Sample : 20220814019908 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 • The test result referred exclusively to the presented test model /sample. • Without written approval of TIRT Inc. the test report shall not reproduced except in full. Lab: Beijing TIRT Technology Service Co.,Ltd Shenzhen Add: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China TEL: +86-0755-27087573 Report No.: FCC022022-5923RF14 Page 3 of 8 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note FCC022022-5924RF14 V1.0 Original Report Dec. 23, 2022 Valid Report No.: FCC022022-5923RF14 Page 4 of 8 1. TEST FACILITY Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab. Designation Number: CN1309 FCC Test Firm Registration Number: 825524 Telephone: +86-0755-27087573 Report No.: FCC022022-5923RF14 Page 5 of 8 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna For WIFI 2.4GHz: Antenna Specification: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 Tenda RX27V1.0 Dipole N/A 4.84 2 Tenda RX27V1.0 Dipole N/A 4.84 3 Tenda RX27V1.0 Dipole N/A 4.84 Note: 1) This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4.84. For power spectral density measurements, N ANT =3, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4.84+10log(3/1)dBi=9.61. Then, the power spectral density limit is 8-(9.61-6)=4.39. 2) Beamforming Gain: 4.5dB. Then Directional gain=4.5+4.84=9.34. So the power limit is 30-(9.34-6)=26.66. The antenna gain and beamforming gain are provided by the manufacturer. Table for Antenna Configuration: Operating Mode TX Mode 1TX 3TX IEEE 802.11b V(Ant. 1) - IEEE 802.11g V(Ant. 1) - IEEE 802.11n(HT20) - V(Ant. 1 + Ant. 2 + Ant. 3) IEEE 802.11n(HT40) - V(Ant. 1 + Ant. 2 + Ant. 3) IEEE 802.11ax(HE20) - V(Ant. 1 + Ant. 2 + Ant. 3) IEEE 802.11ax(HE40) - V(Ant. 1 + Ant. 2 + Ant. 3) Report No.: FCC022022-5923RF14 Page 6 of 8 For WIFI 5GHz: . Antenna Specification: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 Tenda RX27V1.0 Dipole N/A 6.02 2 Tenda RX27V1.0 Dipole N/A 6.02 Note: 1) This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=6.02. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=6.02+10log(2/1)dBi=9.03. Then, the UNII-1 power spectral density limit is 17-(9.03-6)=13.97, the UNII-2A power spectral density limit is 11-(9.03-6)=7.97, the UNII-3 power spectral density limit is 30-(9.03-6)=26.97. 2) Beamforming Gain: 3 dB. Directional gain=6.02+3=9.02 dBi. Then, the UNII-1 and UNII-3 power limit is 30-(9.02-6)=26.98, the UNII-2A power limit is 23.98-(9.02-6)=20.96. 3) The antenna gain and beamforming gain are provided by the manufacturer. 4. Table for Antenna Configuration: Operating Mode TX Mode 1TX 2TX IEEE 802.11a V (Ant. 1) - IEEE 802.11n(HT20) - V (Ant. 1 + Ant. 2) IEEE 802.11n(HT40) - V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT20) - V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT40) - V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT80) - V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT160) - V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) - V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) - V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE80) - V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE160) - V (Ant. 1 + Ant. 2) Report No.: FCC022022-5923RF14 Page 7 of 8 For WIFI 6GHz: . Antenna Specification: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 tp-link N/A Dipole N/A 4.85 2 tp-link N/A Dipole N/A 4.85 Note: 1 This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4.85. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4.85+10log(2/1)dBi=7.86. 2 Beamforming Gain: 3dB. Then the Directional gain=4.85+3=7.85. So the output power limit is 30-(7.85-6)=28.15. 3) The antenna gain and beamforming gain are provided by the manufacturer. 4. Table for Antenna Configuration: Operating Mode TX Mode 2TX IEEE 802.11ax(HE20) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE80) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE160) V (Ant. 1 + Ant. 2) Report No.: FCC022022-5923RF14 Page 8 of 8 3. TEST RESULTS Fo…

Text truncated - open the document above for the full version.

Test Report

Report No.: FCC022022-5924RF0 Page 1 of 250 Product Name: AX5700 Tri-Band Gibabit Wi-Fi 6E Router Report No: FCC022022-5924RF0 Product Model: RX27 Pro;TX27 Pro Security Classification: Open Version: V1.0 Total Page: 250 TIRT Testing Report Prepared By: Checked By: Approved By: Stone Tang Randy Lv Daniel Chen Report No.: FCC022022-5924RF0 Page 2 of 250 FCC DFS Test Report FCC ID: V7TRX27P This report concerns: Original Grant Project No. : 022022-5924 Equipment : AX5700 Tri-Band Gibabit Wi-Fi 6E Router Brand Name : Tenda Test Model : RX27 Pro Series Model : TX27 Pro Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Aug. 12, 2022 Date of Test : Aug. 12, 2022~Sep. 30, 2022 Issued Date : Dec. 23, 2022 Report Version : V1.0 Test Sample : Engineering Sample No.: Standard(s) : FCC CFR Title 47, Part 15, Subpart E RSS-247,Issue 2, Feb. 2017 FCC KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 FCC KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 • The test result referred exclusively to the presented test model /sample. • Without written approval of TIRT Inc. the test report shall not reproduced except in full. Lab: Beijing TIRT Technology Service Co.,Ltd Shenzhen Add: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China TEL: +86-0755-27087573 Report No.: FCC022022-5924RF0 Page 3 of 250 Table of Contents Page REPORT ISSUED HISTORY 4 1 . TEST FACILITY 5 2 . TEST ENVIRONMENT CONDITIONS 5 3 . SUMMARY OF TEST RESULTS 5 4 . GENERAL INFORMATION 6 4.1 GENERAL DESCRIPTION OF EUT 6 4.2 MAXIMUM OUTPUT POWER AND E.I.R.P. 8 4.3 TRANSMIT POWER CONTROL (TPC) 9 4.4 DESCRIPTION OF TEST MODES 11 5 . U-NII DFS RULE REQUIREMENTS 12 5.1 WORKING MODES AND REQUIRED TEST ITEMS 12 5.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS 13 6 . MEASUREMENT INSTRUMENTS LIST 16 7 . DYNAMIC FREQUENCY SELECTION (DFS) 17 7.1 DFS MEASUREMENT SYSTEM 17 7.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL 21 7.3 DEVIATION FROM TEST STANDARD 21 8 . TEST RESULTS 22 8.1 SUMMARY OF DFS TEST RESULT 22 8.2 DFS DETECTION THRESHOLD 23 8.3 RADAR TEST WAVEFORMS 27 8.4 CHANNEL AVAILABILITY CHECK TIME 208 8.5 CHANNEL MOVE TIME AND CHANNEL CLOSING TRANSMISSION TIME 220 8.6 STATISTICAL PERFORMANCE CHECK 225 8.7 NON-OCCUPANCY PERIOD 241 8.8 U-NII DETECTION BANDWIDTH 243 9 . EUT TEST PHOTO 250 Report No.: FCC022022-5924RF0 Page 4 of 250 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note FCC022022-5924RF0 R00 Original Report Dec. 23, 2022 Valid Report No.: FCC022022-5924RF0 Page 5 of 250 1. TEST FACILITY Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab. Designation Number: CN1309 FCC Test Firm Registration Number: 825524 Telephone: +86-0755-27087573 2. TEST ENVIRONMENT CONDITIONS Test Item Temperature Humidity Test Voltage Tested By Dynamic Frequency Selection (DFS) 24°C 52-57% AC120V/60Hz Stone Tang 3. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart E Standard(s) Section Test Item Test Result Judgment Remark FCC 15.407(h) Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) ------ PASS ------ Report No.: FCC022022-5924RF0 Page 6 of 250 4. GENERAL INFORMATION 4.1 GENERAL DESCRIPTION OF EUT Equipment AX5700 Tri-Band Gibabit Wi-Fi 6E Router Brand Name Tenda Test Model RX27 Pro Series Model TX27 Pro Model Difference(s) Only differ in model name. Power Source DC voltage supplied from AC adapter. Model: BN026-A24012U Power Rating I/P: 100-240V~ 50/60Hz 0.7A O/P: 12.0V2.0A Operation Frequency Band(s) UNII-2A: 5250 MHz ~ 5350 MHz Modulation Type IEEE 802.11a/n/ac: OFDM IEEE 802.11ax: OFDMA Bit Rate of Transmitter IEEE 802.11a: 54/48/36/24/18/12/9/6 Mbps IEEE 802.11n: up to 300 Mbps IEEE 802.11ac: up to 1733.4 Mbps IEEE 802.11ax: up to 2402 Mbps Operating Mode(s) Master Client device without radar detection Client device with radar detection Maximum Output Power _UNII-2A Non Beamforming IEEE 802.11ac80: 20.90 dBm (0.1230 W) Maximum Output Power _UNII-2A Beamforming IEEE 802.11ac80: 20.61 dBm (0.1151 W) Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the user's manual. 2. Channel List: IEEE 802.11a IEEE 802.11n(HT20) IEEE 802.11ac(VHT20) IEEE 802.11ax(HE20) IEEE 802.11n(HT40) IEEE 802.11ac(VHT40) IEEE 802.11ax(HE40) IEEE 802.11ac(VHT80) IEEE 802.11ax(HE80) UNII-2A UNII-2A UNII-2A Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 52 5260 54 5270 58 5290 56 5280 62 5310 60 5300 64 5320 IEEE 802.11ac(VHT160) IEEE 802.11ax(HE160) Channel Frequency (MHz) 50 5250 Report No.: FCC022022-5924RF0 Page 7 of 250 3. Antenna Specification: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 Tenda RX27V1.0 Dipole N/A 6.02 2 Tenda RX27V1.0 Dipole N/A 6.02 Note: 1) This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=6.02. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=6.02+10log(2/1)dBi=9.03. Then, the UNII-1 power spectral density limit is 17-(9.03-6)=13.97, the UNII-2A power spectral density limit is 11-(9.03-6)=7.97, the UNII-3 power spectral density limit is 30-(9.03-6)=26.97. 2) Beamforming Gain: 3 dB. Directional gain=6.02+3=9.02 dBi. Then, the UNII-1 and UNII-3 power limit is 30-(9.02-6)=26.98, the UNII-2A power limit is 23.98-…

Text truncated - open the document above for the full version.

Test Report

Report No.: FCC022022-5924RF0 Page 35 of 250 Trial ID Radar Type Number of Bursts Burst Peried(s) Wave from Length (s) Center Frequency(GHz) - 6 Type 5 15 0.8 12 5.32 Burst ID Burst Offset (μs) Pulse Width (μs) Chirp Width (MHz) Number of Pulses per Burst PRI-1 (μs) PRI-2 (μs) PRI-3 (μs) 0 329022 96.6 13 3 1182 1609 1581 1 521718 96.7 13 3 1829 1799 1154 2 714222 86.5 13 3 1923 1396 1865 3 112450 73.3 13 2 1908 1318 - 4 306283 55.8 13 1 1688 - - 5 500239 55.4 13 1 1145 - - 6 690932 85.3 13 3 1336 1504 1820 7 88645 79.4 13 2 1344 1893 - 8 282508 65.7 13 1 1476 - - 9 475842 68.6 13 2 1008 1028 - 10 667887 77.7 13 2 1972 1835 - 11 64845 79.6 13 2 1882 1331 - 12 257755 94.9 13 3 1830 1070 1349 13 452335 61.4 13 1 1451 - - 14 643395 90.6 13 3 1233 1562 1887 7 Type 5 12 1 12 5.32 Burst ID Burst Offset (μs) Pulse Width (μs) Chirp Width (MHz) Number of Pulses per Burst PRI-1 (μs) PRI-2 (μs) PRI-3 (μs) 0 51446 52.6 10 1 1210 - - 1 292696 84.1 10 3 1314 1725 1529 2 533989 97.7 10 3 1139 1868 1805 3 775564 97.3 10 3 1341 1446 1755 4 21542 98.8 10 3 1544 1386 1302 5 263385 72.2 10 2 1771 1184 - 6 505581 67.6 10 2 1175 1027 - 7 747058 75.7 10 2 1026 1871 - 8 989976 60.9 10 1 1798 - - 9 234024 64.2 10 1 1138 - - 10 475207 78.8 10 2 1784 1604 - 11 715825 87.5 10 3 1511 1712 1683 Report No.: FCC022022-5924RF0 Page 36 of 250 Trial ID Radar Type Number of Bursts Burst Peried(s) Wave from Length (s) Center Frequency(GHz) - 8 Type 5 14 0.857142 9 12 5.32 Burst ID Burst Offset (μs) Pulse Width (μs) Chirp Width (MHz) Number of Pulses per Burst PRI-1 (μs) PRI-2 (μs) PRI-3 (μs) 0 823112 54.1 13 1 1415 - - 1 174965 50.7 13 1 1221 - - 2 382216 52.3 13 1 1974 - - 3 587395 99.8 13 3 1558 1696 1949 4 796897 68.4 13 2 1014 1099 - 5 149042 80.8 13 2 1736 1505 - 6 356750 62.5 13 1 1778 - - 7 563824 74.8 13 2 1149 1204 - 8 772314 50.8 13 1 1049 - - 9 123796 54 13 1 1417 - - 10 331215 63 13 1 1730 - - 11 537402 91.8 13 3 1143 1270 1347 12 744805 79.3 13 2 1274 1992 - 13 98172 64.3 13 1 1937 - - 9 Ty…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Shen Yue(Engineer)

[email protected]86-755-27657098Fax: 866-755-27657178

Technical Contact

BTL Inc.Steven Lu

[email protected]+8676983183000

No.3 Jinshagang 1st Rd, Shixia, Dalang · China

Non-Technical Contact

BTL Inc.Rose Liu

[email protected]+8676983183000

Test Firm

Beijing TIRT Technology Service Co.,Ltd ShenzhenQuan Chen

[email protected]+86 150 0208024

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
4	15E	5.25 GHz - 5.25 GHz	52.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 30 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20 MHz, 40 MHz, 80 MHz and 160 MHz bandwidth modes.
