Report No.: BTL-FCCP-3-2011C009 Page 1 of 6 FCC RF EXPOSURE REPORT FCC ID: V7TTX3 Project No. : 2011C009 Equipment : AX1800 Dual Band Gigabit Wi-Fi 6 Router Brand Name : Tenda Test Model : TX3 Series Model : RX3 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Nov. 02, 2020 Date of Test : Nov. 03, 2020 ~ Dec. 04, 2020 Issued Date : Dec. 11, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2020110287 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Simon Ling Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-3-2011C009 Page 2 of 6 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Dec. 11, 2020 Report No.: BTL-FCCP-3-2011C009 Page 3 of 6 1. TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3,Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. BTL's Test Firm Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: For WLAN 2.4GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 5 2 N/A N/A Dipole N/A 5 Note: 1) This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=5. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=5+10log(2/1)dBi=8.01. Then, the power spectral density limit is 8-(8.01-6)=5.99. 2) Beamforming Gain: 3 dB. So Directional gain=5+3=8. Then, the power limit is 30-(8-6)=28.00. 3) The antenna gain is provided by the manufacturer. Table for Antenna Configuration: For Non Beamforming: Operating Mode TX Mode 1TX 2TX IEEE 802.11b V (Ant. 1) - IEEE 802.11g V (Ant. 1) - IEEE 802.11n(HT20) - V (Ant. 1+Ant. 2) IEEE 802.11n(HT40) - V (Ant. 1+Ant. 2) IEEE vht20 - V (Ant. 1+Ant. 2) IEEE vht40 - V (Ant. 1+Ant. 2) IEEE 802.11ax(HE20) - V (Ant. 1+Ant. 2) IEEE 802.11ax(HE40) - V (Ant. 1+Ant. 2) Report No.: BTL-FCCP-3-2011C009 Page 4 of 6 For Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n(HT20) V (Ant. 1+Ant. 2) IEEE 802.11n(HT40) V (Ant. 1+Ant. 2) IEEE vht20 V (Ant. 1+Ant. 2) IEEE vht40 V (Ant. 1+Ant. 2) IEEE 802.11ax(HE20) V (Ant. 1+Ant. 2) IEEE 802.11ax(HE40) V (Ant. 1+Ant. 2) For WLAN 5GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 4 2 N/A N/A Dipole N/A 4 Note: 1) This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4+10log(2/1)dBi=7.01. Then, the UNII-1 power spectral density limit is 17-(7.01-6)=15.99, the UNII-3 power spectral density limit is 30-(7.01-6)=28.99 2) Beamforming Gain: 3 dB. So Directional gain=4+3=7. Then, the power limit is 30-(7-6)=29.00. 3) The antenna gain is provided by the manufacturer. Table for Antenna Configuration: For Non Beamforming: Operating Mode TX Mode 1TX 2TX IEEE 802.11a V (Ant. 1) - IEEE 802.11n(HT20) - V (Ant. 1+Ant. 2) IEEE 802.11n(HT40) - V (Ant. 1+Ant. 2) IEEE 802.11ac(VHT20) - V (Ant. 1+Ant. 2) IEEE 802.11ac(VHT40) - V (Ant. 1+Ant. 2) IEEE 802.11ac(VHT80) - V (Ant. 1+Ant. 2) IEEE 802.11ax(HE20) - V (Ant. 1+Ant. 2) IEEE 802.11ax(HE40) - V (Ant. 1+Ant. 2) IEEE 802.11ax(HE80) - V (Ant. 1+Ant. 2) Report No.: BTL-FCCP-3-2011C009 Page 5 of 6 For Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n(HT20) V (Ant. 1+Ant. 2) IEEE 802.11n(HT40) V (Ant. 1+Ant. 2) IEEE 802.11ac(VHT20) V (Ant. 1+Ant. 2) IEEE 802.11ac(VHT40) V (Ant. 1+Ant. 2) IEEE 802.11ac(VHT80) V (Ant. 1+Ant. 2) IEEE 802.11ax(HE20) V (Ant. 1+Ant. 2) IEEE 802.11ax(HE40) V (Ant. 1+Ant. 2) IEEE 802.11ax(HE80) V (Ant. 1+Ant. 2) Report No.: BTL-FCCP-3-2011C009 Page 6 of 6 3. TEST RESULTS For 2.4GHz Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 8.01 6.3241 20.18 104.2317 0.13120 1 Complies For 2.4GHz Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 8.00 6.3096 19.18 82.7942 0.10398 1 Complies For 5GHz UNII-1 Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 7.01 5.0234 26.57 453.9416 0.45389 1 Complies For 5GHz UNII-1 Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 7.00 5.0119 26.66 463.4469 0.46233 1 Complies For 5GHz UNII-3 Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit …

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2011C009 Page 1 of 245 FCC Radio Test Report FCC ID: V7TTX3 This report concerns: Original Grant Project No. : 2011C009 Equipment : AX1800 Dual Band Gigabit Wi-Fi 6 Router Brand Name : Tenda Test Model : TX3 Series Model : RX3 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Nov. 02, 2020 Date of Test : Nov. 03, 2020 ~ Dec. 04, 2020 Issued Date : Dec. 11, 2020 Report Version : R00 Test Sample : Engineering Sample No.:DG2020110287 for conducted, DG2020110290 for radiated Standard(s) : FCC Part15, Subpart E(15.407) ANSI C63.10-2013 FCC KDB 789033 D02 General UNII Test Procedures New Rules v02r01 FCC KDB 662911 D01 Multiple Transmitter Output v02r01 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Simon Ling Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-2011C009 Page 2 of 245 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2011C009 Page 3 of 245 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 TEST MODES 13 2.3 PARAMETERS OF TEST SOFTWARE 17 2.4 DUTY CYCLE 19 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 22 2.6 SUPPORT UNITS 22 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 23 3.1 LIMIT 23 3.2 TEST PROCEDURE 23 3.3 DEVIATION FROM TEST STANDARD 23 3.4 TEST SETUP 24 3.5 EUT OPERATION CONDITIONS 24 3.6 TEST RESULTS 24 4 . RADIATED EMISSIONS TEST 25 4.1 LIMIT 25 4.2 TEST PROCEDURE 26 4.3 DEVIATION FROM TEST STANDARD 26 4.4 TEST SETUP 27 4.5 EUT OPERATION CONDITIONS 28 4.6 TEST RESULTS - 9 KHZ to 30 MHZ 28 4.7 TEST RESULTS - 30 MHz TO 1000 MHz 28 4.8 TEST RESULTS - ABOVE 1000 MHz 28 5 . BANDWIDTH TEST 29 5.1 LIMIT 29 5.2 TEST PROCEDURE 29 5.3 DEVIATION FROM STANDARD 29 5.4 TEST SETUP 29 Report No.: BTL-FCCP-2-2011C009 Page 4 of 245 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 29 5.6 TEST RESULTS 29 6 . MAXIMUM OUTPUT POWER TEST 30 6.1 LIMIT 30 6.2 TEST PROCEDURE 30 6.3 DEVIATION FROM STANDARD 30 6.4 TEST SETUP 30 6.5 EUT OPERATION CONDITIONS 30 6.6 TEST RESULTS 30 7 . POWER SPECTRAL DENSITY TEST 31 7.1 LIMIT 31 7.2 TEST PROCEDURE 31 7.3 DEVIATION FROM STANDARD 31 7.4 TEST SETUP 32 7.5 EUT OPERATION CONDITIONS 32 7.6 TEST RESULTS 32 8 . FREQUENCY STABILITY MEASUREMENT 33 8.1 LIMIT 33 8.2 TEST PROCEDURE 33 8.3 DEVIATION FROM STANDARD 33 8.4 TEST SETUP 33 8.5 EUT OPERATION CONDITIONS 33 8.6 TEST RESULTS 33 9 . MEASUREMENT INSTRUMENTS LIST 34 10 . EUT TEST PHOTOS 36 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 40 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 45 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1 GHZ 50 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 53 APPENDIX E - BANDWIDTH 176 APPENDIX F - MAXIMUM OUTPUT POWER 191 APPENDIX G - POWER SPECTRAL DENSITY 225 Report No.: BTL-FCCP-2-2011C009 Page 5 of 245 Table of Contents Page APPENDIX H - FREQUENCY STABILITY 243 Report No.: BTL-FCCP-2-2011C009 Page 6 of 245 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Dec. 11, 2020 Report No.: BTL-FCCP-2-2011C009 Page 7 of 245 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart E(15.407) Standard(s) Section Test Item Test Result Judgment Remark 15.207 15.407(b) AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.407(b) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.407(a) 15.407(e) Spectrum Bandwidth APPENDIX E PASS ------ 15.407(a) Maximum Output Power APPENDIX F PASS ------ 15.407(a) Power Spectral Density APPEN…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2011C009 Page 175 of 245 Test Mode: TX WLAN 2.4G G Mode 2437MHz + WLAN 5G AX20 Mode 5240MHz Horizontal REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-2011C009 Page 176 of 245 APPENDIX E - BANDWIDTH Report No.: BTL-FCCP-2-2011C009 Page 177 of 245 Test Mode UNII-1_TX A Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 36 5180 21.65 17.20 40 5200 35.90 18.40 48 5240 40.10 19.40 CH36 CH40 CH48 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 178 of 245 Test Mode UNII-3_TX A Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 149 5745 16.50 35.10 500 Complies 157 5785 16.40 35.20 500 Complies 165 5825 16.45 37.20 500 Complies CH149 CH157 CH165 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 179 of 245 Test Mode UNII-1_TX AC(VHT20) Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 36 5180 22.05 18.20 40 5200 28.00 18.60 48 5240 41.45 19.60 CH36 CH40 CH48 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 180 of 245 Test Mode UNII-1_TX AC(VHT40) Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 38 5190 40.10 37.00 46 5230 41.60 37.20 CH38 CH46 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 181 of 245 Test Mode UNII-1_TX AC(VHT80) Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 42 5210 82.80 76.40 CH42 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 182 of 245 Test Mode UNII-3_TX AC(VHT20) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 149 5745 17.69 40.60 500 Complies 157 5785 17.10 40.40 500 Complies 165 5825 17.35 39.80 500 Complies CH149 CH157 CH165 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 183 of 245 Test Mode UNII-3_TX AC(VHT40) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 151 5755 36.50 81.80 500 Complies 159 5795 36.50 81.40 500 Complies CH151 CH159 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 184 of 245 Test Mode UNII-3_TX AC(VHT80) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 155 5775 75.80 156.80 500 Complies CH155 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 185 of 245 Test Mode UNII-1_TX AX(HE20) Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 36 5180 21.70 19.20 40 5200 26.05 19.20 48 5240 43.35 19.80 CH36 CH40 CH48 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 186 of 245 Test Mode UNII-1_TX AX(HE40) Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 38 5190 39.90 38.20 46 5230 41.40 38.40 CH38 CH46 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 187 of 245 Test Mode UNII-1_TX AX(HE80) Mode Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 42 5210 82.00 77.60 CH42 26 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 188 of 245 Test Mode UNII-3_TX AX(HE20) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 149 5745 17.80 40.80 500 Complies 157 5785 16.50 40.40 500 Complies 165 5825 17.70 40.00 500 Complies CH149 CH157 CH165 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 189 of 245 Test Mode UNII-3_TX AX(HE40) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 151 5755 37.10 81.20 500 Complies 159 5795 37.19 81.60 500 Complies CH151 CH159 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 190 of 245 Test Mode UNII-3_TX AX(HE80) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 155 5775 73.00 159.20 500 Complies CH155 6 dB Bandwidth 99 % Emission Bandwidth Report No.: BTL-FCCP-2-2011C009 Page 191 of 245 APPENDIX F - MAXIMUM OUTPUT POWER Report No.: BTL-FCCP-2-2011C009 Page 192 of 245 Non Beamforming Test Mode UNII-1_TX A Mode Channel Frequency (MHz) Output Power (dBm) Duty Factor Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 36 5180 19.03 0.21 19.24 30.00 1.00 Complies 40 5200 21.96 0.21 22.17 30.00 1.00 Complies 48 5240 24.58 0.21 24.79 30.00 1.00 Complies Test Mode UNII-3_TX A Mode Channel Frequency (MHz) Output Power (dBm) Duty Factor Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 149 5745 24.75 0.21 24.96 30.00 1.00 Complies 157 5785 24.84 0.21 25.05 30.00 1.00 Complies 165 5825 24.71 0.21 24.92 30.00 1.00 Complies Report No.: BTL-FCCP-2-2011C009 Page 193 of 245 Test Mode UNII-1_TX N(HT20) Mode_Ant. 1 Channel Frequency (MHz) Output Power (dBm) Duty Factor Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 36 5180 16.09 0.23 16.32 30.00 1.00 Complies 40 5200 19.64 0.23 19.87 30.00 1.00 Complies 48 5240 22.82 0.23 23.05 30.00 1.00 Complies Test Mode UNII-1_TX N(HT20) Mode_Ant. 2 Channel Frequency (MHz) Output Power (dBm) Duty Factor Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 36 5180 16.79 0.23 17.02 30.00 1.00 Complies 40 5200 19.95 0.23 20.18 30.00 1.00 Complies 48 5240 23.06 0.23 23.29 30.00 1.00 Complies Test Mode UNII-1_TX N(HT20) Mode_Total Channel Frequency (MHz) Output Power (dBm) Max. Limit (dBm) Max. Limit (W) Result 36 5180 19.69 30.00 1.00 Complies 40 5200 23.04 30.00 1.00 Complies 48 5240 26.18 30.00 1.00 Complies Report No.: BTL-FCCP-2-2011C009 Page 194 of 245 Test Mode UNII-1_TX N(HT40) Mode_Ant…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2011C009 Page 32 of 161 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-2011C009 Page 33 of 161 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-2011C009 Page 34 of 161 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-1-2011C009 Page 35 of 161 Radiated Emissions Test Photos Above 1 GHz
