V7TW300AWireless-N Access Point

300M Wireless-N Access Point 300M Wireless-N Access Point Copyright Statement is the registered trademark of Shenzhen Tenda Technology Co., Ltd. All the products and product names mentioned herein are the trademarks or registered trademarks of their respective holders. Copyright of the whole product as integration, including its accessories and software, belongs to Shenzhen Tenda Technology Co., Ltd. Without the permission of Shenzhen Tenda Technology Co., Ltd, any individual or party is not allowed to copy, plagiarize, imitate or translate it into other languages. All the photos and product specifications mentioned in this manual are for references only. As the upgrade of software and hardware, there will be changes. And if there are changes, Tenda is not responsible for informing in advance. If you want to know more about our product information, please visit our website at www.tenda.cn. 300M Wireless-N Access Point Content Chapter 1 Product Overview .........................1 1.1 Features ..........................................2 1.2 Package Contents..............................3 1.3 LED Indicator and Panel Description.....4 Chapter 2 Hardware Installation ....................7 Chapter 3 Web Configuration ........................9 3.1 Web Login........................................9 3.2 Wizard........................................... 11 3.3 Running Status ............................... 12 3.4 LAN Settings .................................. 13 Chapter 4 Wireless Settings ........................ 15 4.1 Working Mode................................. 15 4.1.1 Access Point (AP) Mode .............. 16 4.1.2 P2P (Point to Point) Bridge Mode.. 32 4.1.3 P2MP Bridge Mode ..................... 37 4.1.4 Wireless Repeater Mode ............. 42 4.1.5 Wireless Client Mode .................. 49 4.2 Advanced Settings .......................... 53 300M Wireless-N Access Point 4.3 WPS Settings.................................. 55 4.4 Access Control ................................ 57 4.5 Connection Status ........................... 59 4.6 PING ............................................. 60 Chapter 5 SNMP Setting ............................. 61 5.1 SNMP Introduction .......................... 61 5.2 SNMP Setting ................................. 62 Chapter 6 System Tools ............................. 64 6.1 Password Change............................ 64 6.2 Restore to Factory............................. 65 6.3 Backup/Restore .............................. 66 6.4 Time Settings ................................. 67 6.5 Reboot System ............................... 68 6.6 Firmware Upgrade........................... 68 6.7 Syslog ........................................... 70 Appendix I: Glossary ................................. 71 Appendix II: TCP/IP Address Setting (Take Winxp as example) ............................................. 74 300M Wireless-N Access Point 1 Chapter 1 Product Overview W300A, with 2T3R antennas, is an IEEE802.11n (Draft 2.0)-compliant wireless access point with one Gigabit LAN switch port, which utilizes the latest MIMO technology and provides up to 300Mbps stable transmission rate from wireless radio to wired network. With backward compatible with IEEE802.11b/g device, it is suitable for SOHOs and small-sized enterprises to share the wireless network. W300A supports five working modes: wireless AP mode for other wireless access; Repeater mode for relaying wireless network coverage; P2P, P2MP mode for bridging two or more wireless network and wireless client mode. Besides, it supports multiple encryption methods like 64/128bit WEP, WPA, WPA2 and WPA&WPA2 to protect you network against malicious attack, and WPS can free you from remembering long passwords. Power over Ethernet support can realize data transmission and power supply via one Ethernet cable. Moreover, SNMP and Web-based management interface can help users configure the device more easily. 300M Wireless-N Access Point 2 1.1 Features ¾ Complies with IEEE802.11n (Draft 2.0), IEEE802.11b and IEEE802.11g standards ¾ Supports five working modes: wireless AP, Repeater, P2P, P2MP and wireless client ¾ Provides 300Mbps receiving rate and 300Mbps sending rate ¾ MIMO technology utilizes reflection signal to increase 8 times transmission distance of original 802.11g standard and reduces the "dead spots" in the wireless coverage area ¾ Provides one Gigabit Auto-negotiation RJ45 port for LAN connection ¾ Supports two power supply ways: Power over Ethernet and external power adapter ¾ Supports SNMP and Web-based management interface ¾ Supports 64/128bit WEP encryption ¾ Supports multiple encryption methods as WPA, WPA2 and WPA&WPA2 and security mechanism ¾ Supports WPS (PBC and PIN) encryption method to free you from remembering long passwords ¾ Supports five connection modes: AP, WDS P2P 300M Wireless-N Access Point 3 Bridge, WDS P2MP Bridge, WDS AP Bridge and Client ¾ Supports Auto MDI/MDIX ¾ Supports Firefox1.0, IE5.5 or above ¾ Supports authorization access over thirty-two MAC addresses ¾ Supports auto wireless channel selection ¾ Provides three detachable antennas Wireless local network usually is used in a planned environment where each access point is located steadily and with stable radio coverage area. The AP (Access Point) will provide wireless communication service for users around. 1.2 Package Contents Please unpack the package and find the following items: ¾ One W300A Wireless AP ¾ One Power Adapter ¾ One Quick Installation Guide ¾ One CD-ROM 300M Wireless-N Access Point 4 If any of listed items are missing or damaged, please contact the Tenda reseller from whom you purchased for replacement immediately. 1.3 LED Indicator and Panel Description z LED indicator description on front panel (from L to R) WPS When blinking, it indicates the device is negotiating with client in WPS mode. POWER When turns green, Always ON indicates the power connects well. 300M Wireless-N Access Point 5 SYS When turns green, blinking …

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1005C175 Page 2 of 11 1005C175 Neutron Engineering Inc. Project No.: 1005C175 Page 3 of 11 1005C175 1005C175 Neutron Engineering Inc. Project No.: 1005C175 Page 3 of 11 1005C175 1005C175

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1005C175 Page 111 of 112 10. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1005C175 Page 111 of 112 10. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1005C175 Page 112 of 112 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1005C175 Page 112 of 112 Radiated Measurement Photos
