V7TWH302AWireless N300 High Power Access Point

300M Wireless AP 1 . 300M Wireless AP 2 Copyright Statement is the registered trademark of Shenzhen Tenda Technology Co., Ltd. All the products and product names mentioned herein are the trademarks or registered trademarks of their respective holders. Copyright of the whole product as integration, including its accessories and software, belongs to Shenzhen Tenda Technology Co., Ltd. No part of this publication can be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the prior written permission of Shenzhen Tenda Technology Co., Ltd. If you would like to know more about our product information, please visit our website at http://www.tendacn.com. Disclaimer Pictures, images and product specifications herein are for references only. To improve internal design, operational function, and/or reliability, Tenda reserves the right to make changes to the products described in this document without obligation to notify any person or organization of such revisions or changes. Tenda does not assume any liability that may occur due to the use or application of the product or circuit layout(s) described herein. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information and recommendations in this document do not constitute the warranty of any kind, express or implied. 300M Wireless AP 3 Preface Thank you for choosing Tenda! Please read this user guide before you start! This user guide instructs you to install and configure the device. Convention Icon Description Note This format is used to highlight information of importance or special interest. Ignoring this type of note may result in ineffective configurations, loss of data or damage to device. Tip This format is used to highlight a procedure that will save time or resources. Technical Support: Website: http://www.tendacn.com Telephone: (86 755) 2765 7180 Email: [email protected] 300M Wireless AP 4 Contents Contents .......................................................................................................................................................................... 4 Chapter 1 Product Overview ............................................................................................................................................ 6 1.1 Package Contents ............................................................................................................................................................. 6 1.2 Hardware Description ...................................................................................................................................................... 6 LEDs, Interfaces and Buttons ............................................................................................................................................. 6 1.3 Installation Considerations ............................................................................................................................................... 7 Chapter 2 Installation ...................................................................................................................................................... 8 2.1 Physical Installation .......................................................................................................................................................... 8 2.2 Configure Your PC ........................................................................................................................................................... 10 2.3 Connect to Your Device Wirelessly ................................................................................................................................. 10 Windows 7 ....................................................................................................................................................................... 11 Windows XP ..................................................................................................................................................................... 12 Chapter 3 Advanced Settings ......................................................................................................................................... 14 3.1 Web Login ....................................................................................................................................................................... 14 3.2 Status .............................................................................................................................................................................. 15 3.2.1 System Status ......................................................................................................................................................... 15 3.2.2 Wireless Status ....................................................................................................................................................... 15 3.2.3 Traffic Statistics ....................................................................................................................................................... 15 3.2.4 Wireless Clients ...................................................................................................................................................... 16 3.3 Quick Setup .................................................................................................................................................................... 16 3.3.1 AP Mode ................................................................................................................................................................. 16 3.3.2 WDS Mode .............................................................................................................................................................. 17 3.3.3 AP Client Mode ............…

Text truncated - open the document above for the full version.

RV-0000000 Project No.: 1406C040 Page 2 of 9 RV-0000000 Project No.: 1406C040 Page 3 of 9 RV-0000000 Project No.: 1406C040 Page 4 of 9 RV-0000000 Project No.: 1406C040 Page 5 of 9

ODEHOORFDWLRQ

RV-0000000 Project No.: 1406C040 Page 5 of 8 RV-0000000 Project No.: 1406C040 Page 6 of 8 RV-0000000 Project No.: 1406C040 Page 7 of 8 RV-0000000 Project No.: 1406C040 Page 8 of 8

Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: V7TWH302A Project No. : 1406C040 Equipment : Wireless N300 High Power Access Point Model : WH302A Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Page 2 of 4 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain(dBi) Note 1 N/A N/A Printed Antenna N/A 2 2 N/A N/A Printed Antenna N/A 2 Page 3 of 4 TEST RESULTS EUT： Wireless N300 High Power Access Point Model Name : WH302A Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2 1.5849 23.3 213.7962 0.067445091 Complies 2 1.5849 23.3 213.7962 0.067445091 Complies 2 1.5849 23.5 223.8721 0.070623681 Complies EUT： Wireless N300 High Power Access Point Model Name : WH302A Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2 1.5849 25.1 323.5937 0.102082281 Complies 2 1.5849 25.1 323.5937 0.102082281 Complies 2 1.5849 25 316.2278 0.099758611 Complies Page 4 of 4 EUT： Wireless N300 High Power Access Point Model Name : WH302A Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2 1.5849 26.07 404.5759 0.127629291 Complies 2 1.5849 26 398.1072 0.125588641 Complies 2 1.5849 26.21 417.8304 0.131810611 Complies EUT： Wireless N300 High Power Access Point Model Name : WH302A Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-40M MODE_Total /CH03, CH06, CH09 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2 1.5849 26.77 475.3352 0.149951351 Complies 2 1.5849 26.81 479.7334 0.151338831 Complies 2 1.5849 26.76 474.2420 0.149606471 Complies Note: the calculated distance is 20 cm.

Report No.: NEI-FCCP-1-1406C040 Page 1 of 148 FCC Radio Test Report FCC ID: V7TWH302A This report concerns (check one): Original Grant Class II Change Project No. : 1406C040 Equipment : Wireless N300 High Power Access Point Model Name : WH302A Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen,China.518052 Tested by: BTL Inc. Date of Receipt: May. 07, 2014 Date of Test: May. 07, 2014 ~ Jun. 24, 2014 Issued Date: Jun. 25, 2014 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Report No.: NEI-FCCP-1-1406C040 Page 2 of 148 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-1-1406C040 Page 3 of 148 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 20 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 20 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 20 5 . BANDWIDTH TEST 21 5.1 APPLIED PROCEDURES 21 5.1.1 TEST PROCEDURE 21 5.1.2 DEVIATION FROM STANDARD 21 5.1.3 TEST SETUP 21 5.1.4 EUT OPERATION CONDITIONS 21 5.1.5 EUT TEST CONDITIONS 21 Report No.: NEI-FCCP-1-1406C040 Page 4 of 148 Table of Contents Page 5.1.6 TEST RESULTS 21 6 . MAXIMUM OUTPUT POWER TEST 22 6.1 APPLIED PROCEDURES / LIMIT 22 6.1.1 TEST PROCEDURE 22 6.1.2 DEVIATION FROM STANDARD 22 6.1.3 TEST SETUP 22 6.1.4 EUT OPERATION CONDITIONS 22 6.1.5 EUT TEST CONDITIONS 22 6.1.6 TEST RESULTS 22 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 23 7.1 APPLIED PROCEDURES / LIMIT 23 7.1.1 TEST PROCEDURE 23 7.1.2 DEVIATION FROM STANDARD 23 7.1.3 TEST SETUP 23 7.1.4 EUT OPERATION CONDITIONS 23 7.1.5 EUT TEST CONDITIONS 23 7.1.6 TEST RESULTS 23 8 . POWER SPECTRAL DENSITY TEST 24 8.1 APPLIED PROCEDURES / LIMIT 24 8.1.1 TEST PROCEDURE 24 8.1.2 DEVIATION FROM STANDARD 24 8.1.3 TEST SETUP 24 8.1.4 EUT OPERATION CONDITIONS 24 8.1.5 EUT TEST CONDITIONS 24 8.1.6 TEST RESULTS 24 9 . MEASUREMENT INSTRUMENTS LIST 25 10 . EUT TEST PHOTO 27 ATTACHMENT A - CONDUCTED EMISSION 31 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 34 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 36 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 43 ATTACHMENT E - BANDWIDTH 92 ATTACHMENT F - MAXIMUM OUTPUT POWER 105 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 109 ATTACHMENT H - POWER SPECTRAL DENSITY 134 Report No.: NEI-FCCP-1-1406C040 Page 5 of 148 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1406C040 Original Issue. Jun. 25, 2014 Report No.: NEI-FCCP-1-1406C040 Page 6 of 148 1. CERTIFICATION Equipment : Wireless N300 High Power Access Point Brand Name : Tenda Model Name : WH302A Applicant : NETIS SYSTEMS CO., LTD Date of Test : May. 07, 2014 ~ Jun. 24, 2014 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1406C040) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: NEI-FCCP-1-1406C040 Page 7 of 148 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Item Judgment Remark FCC 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious Emission PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.247(e) Power Spectral Density PASS …

Text truncated - open the document above for the full version.

Report No.: NEI-FCCP-1-1406C040 Page 27 of 148 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: NEI-FCCP-1-1406C040 Page 28 of 148 Radiated Measurement Photos 9KHz to 30MHz Report No.: NEI-FCCP-1-1406C040 Page 29 of 148 Radiated Measurement Photos 30MHz to 1000MHz Report No.: NEI-FCCP-1-1406C040 Page 30 of 148 Radiated Measurement Photos Above 1000MHz
