VOB-E1729NB105 NGFF WWAN MODULE

DS027 | January 9 th 2014 NVIDIA CONFIDENTIAL | Prepared and Provided Under NDA Datasheet NVIDIA NB105-N NGFF WWAN MODULE SUMMARY DATASHEET NVIDIA CONFIDENTIAL NVIDIA NB105-N NGFF WWAN module summary datasheet RN_06821-R18 | ii RN_06821-R18 DOCUMENT CHANGE HISTORY DS027 Version Date Authors Description of Change 1.0 8 Jan 2014 shixiangc Initial release 1.1 2014-01-20 shixiangc Figure 3 updated NVIDIA CONFIDENTIAL NVIDIA NB105-N NGFF WWAN module summary datasheet DS027 | iii TABLE OF CONTENTS 1.0 NVIDIA NB105-N NGFF WWAN MODULE .................................................... 4 1.1 General features .................................................................................... 4 1.2 Statements .......................................................................................... 7 1.3 Product images ...................................................................................... 8 LIST OF FIGURES Figure 1: Module mechanical drawing based on PCIe M.2 Type 3042 specification ..................... 5 Figure 2: NVIDIA NB105-N module top view .......................................................................... 8 Figure 3: NVIDIA NB105-N module bottom view .................................................................... 8 NVIDIA CONFIDENTIAL NVIDIA NB105-N NGFF WWAN module summary datasheet DS027 | 4 1.0 NVIDIA NB105-N NGFF WWAN MODULE NVIDIA NB105-W NGFF WWAN module is a 2G/3G/4G mobile broadband data-only module. It is primarily designed for North and Latin America, but can also be used in other parts of the world. It is in PCIe M.2 form factor and will be powered by batteries. 1.1 GENERAL FEATURES • LTE FDD : Band 2/4/5/7/17 • DC-HSPA+/HSPA+/HSPA/UMTS: Band 1/2/5 • GSM/GPRS/EDGE: 1900/1800/900/850 MHz • LTE DL 2*2 MIMO • Receive diversity in all DC-HSPA+/HSPA+/LTE bands • Transmit Power: LTE: +23dBm (3GPP TS 36.101 R8 Power Class 3) DC-HSPA+/HSPA+: +23dBm (3GPP TS 34.121 Power Class 3) EDGE 900M/850MHz: +26dBm (3GPP TS 45.005 Power Class E2) EDGE 1900MHz/1800MHz: +25dBm (3GPP TS 45.005 Power Class E2) GSM/GPRS 900M/850MHz: +32dBm (3GPP TS 45.005 Power Class 4) GSM/GPRS 1900MHz/1800MHz: +29dBm (3GPP TS 45.005 Power Class 1) • AT commands: 3GPP TS 27.007 and 27.005 NVIDIA proprietary AT commands Release Notes NVIDIA CONFIDENTIAL NVIDIA NB105-N NGFF WWAN module summary datasheet DS027 | 5 • Power supply: 3.2 V to 4.6V • Temperature range: -10°C to 55°C • Dimensions: PCIe M.2 Type 3042 form factor 42 mm x 30 mm x 2.3 mm Figure 1: Module mechanical drawing based on PCIe M.2 Type 3042 specification • Weight: 6g • USB driver: CDC-ACM CDC-NCM MBIM • Data Features: LTE UL (50 Mbps)/DL (100 Mbps) (CAT3) DC-HSPA+ :UL (5.76 Mbps)/DL (42 Mbps) HSPA+ :UL (5.76 Mbps)/DL (21 Mbps) WCDMA PS: UL (384 kbps)/ DL (384 kbps) EDGE: UL (236.8 kbps)/ DL (236.8 kbps) GPRS: UL (85.6 kbps)/ DL (85.6 kbps) Release Notes NVIDIA CONFIDENTIAL NVIDIA NB105-N NGFF WWAN module summary datasheet DS027 | 6 • SMS MO / MT PDU mode • Location based services eCID SUPL2.0 (requires 3rd party SW & HW platform integration) • Additional features SAR sensor: 2 proximity sensors are supported for PA power backoff SIM hot-plug • Interface PCIe M.2 75 pins HSIC or USB data interface 2 Antenna ports (main and diversity): -- 50 Ohm low profile standard MHF4 coaxial connectors per PCIe M.2 spec SIM card interface (1.8/3.0V) plus SIM detect signal line SAR GPIO OC (over current notification) I2S for audio GPIOs Power supply Reset • Approval and Certifications FCC PTCRB RoHS Compliant Release Notes NVIDIA CONFIDENTIAL NVIDIA NB105-N NGFF WWAN module summary datasheet DS027 | 7 1.2 STATEMENTS Federal Communications Commission (FCC) Statements: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including any interference that may cause undesired operation of the device. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Warning: The FCC requires that you be notified that any changes or modifications to this device not expressly approved by the manufacturer could void the user’s authority to operate the equipment. RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Only those antennas with same type and lesser gain filed under this FCC ID number can be used with this device. The final system integrator must ensure there is no instruction provided in the user manual or customer documentation indicating how to install or remove the transmitter module. Required end product labeling: Any device incorporating this module must include an external, v…
