X3ZBTMOD3BLUETOOTH MODULE

Amp'ed RF Technology

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Jul 31, 2011
Application Purpose: Original Equipment
Date of Application: Jul 31, 2011
Equipment Note: BLUETOOTH MODULE
Frequency Range: 2402.00000000 - 2480.00000000
Company: Amp'ed RF Technology
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Amp’ed RF Technology, Inc. Rev: 1.0 7/21/2011 BT31 Bluetooth Module OEM General User and Installation Guide I. OEM Usage Instructions Installation The BT31 is a surface mount Bluetooth module supplied on a 24 pin, 6-layer PCB. The final assembly recommended reflow profiles are: For RoHS/Pb-free applications, Sn96.5/Ag3.0/Cu0.5 solder is recommended.  Maximum peak temperature of 230° - 240°C (below 250°C).  Maximum rise and fall slope after liquidous of < 2°C/second.  Maximum rise and fall slope after liquidous of < 3°C/second.  Maximum time at liquidous of 40 – 80 seconds. Layout The area around the BT31 module should be free of any ground planes, trace routings, or metal for at least 6mm from the antenna in all directions. Traces should not be routed underneath the module. Crystal Tuning and Power Calibration These steps are performed by the manufacturer, and must NOT be modified from the settings applied during manufacturing. Any changes to these settings may void the user’s authority to operate this equipment. Operating Conditions The permitted operating and storage temperatures, power supply requirements, and I/O tolerances are specified in the BT31 Datasheet. RF Exposure Warning This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device's external antenna must be installed in accordance with provided instructions and it must be operated with a minimum of 20 cm spacing between antennas and all persons’ bodies (excluding extremities of hands, wrists and feet) during wireless mode of operation. Further, this transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Amp’ed RF Technology, Inc. Rev: 1.0 7/21/2011 II. Notice of FCC Regulatory Compliance This module has been tested and found to comply with the FCC Part15 Rules. These limits are designed to provide reasonable protection against harmful interference in approved installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications or changes to this equipment not expressly approved by Amp’ed RF Technology Inc. may void the user’s authority to operate this equipment. III. Modular Approval FCC ID: X3ZBTMOD3 In accordance with FCC Part 15, the BT31 is listed above as a Modular Transmitter device. In support of the Modular Transmitter Approval, the following is stated: 1. The module does have its own RF shielding. 2. The module does have buffered modulation / data inputs. 3. The module does regulate its own power supply. 4. The module does have a permanently attached antenna. 5. The module can be tested as a stand-alone device. 6. The module is labeled with the proper FCC ID, and labeling instructions are provided to OEM end users for external product labels. 7. The module does have instruction for proper use. 8. The module does meet the FCC RF regulations. IV. FCC Label Instructions The outside of final products that contain a BT31 device must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: X3ZBTMOD3” or “Contains FCC ID: X3ZBTMOD3.” Any similar wording that expresses the same meaning may be used. An example of this label is figure 1 below: Amp’ed RF Technology, Inc. Rev: 1.0 7/21/2011 Figure 1: External Device FCC Label Sample Model: BT31 Input 2.5VDC 50mA Made in China Amp’ed RF Technology Contains Transmitter Module FCC ID: X3ZBTMOD3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Cover Letter(s)

FCC Confidential Authorization 28 July, 2011 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: X3ZBTMOD3. In accordance with sections 0.457 and 0.459 of the Commission’s Rules, Amp’ed RF Technology Inc. hereby requests long-term confidential treatment of information accompanying this application as outline below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Kelly Simone 1879 Lundy Ave, Suite 138 San Jose, CA 95131 408-213-9530

External Photos

ID Label/Location Info

Amp’ed RF Technology BT31 Input 2.5VDC 50mA Made in China FCC ID: X3ZBTMOD3

ID Label/Location Info

Model:BT31 Input 2.5VDC 50mA Made in China Amp’ed RF Technology Contains Transmitter Module FCC ID: X3ZBTMOD3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ID Label/Location Info

Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 APPENDIX E FCC & IC Labeling FC C Part 15.247 & IC RSS-210 R eport Number: M110720E1 Page 96 of 110 Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 (1) FCC ID Label Requirements As per FCC §2.925, (a) Each equipment covered in an application for equipment authorization shall bear a nameplate or label listing the following: (1) FCC Identifier consisting of the two elements in the exact order specified in §2.926. The FCC Identifier shall be preceded by the term FCC ID in capital letters on a single line, and shall be of a type size large enough to be legible without the aid of magnification. Example: FCC ID XXX123. XXX—Grantee Code 123—Equipment Product Code As per FCC §15.19, (a) In addition to the requirements in part 2 of this chapter, a device subject to certification, or verification shall be labeled as follows: (3) All other devices shall bear the following statement in a conspicuous location on the device: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. (4) Where a device is constructed in two or more sections connected by wires and marketed together, the statement specified above is required to be affixed only to the main control unit. If the EUT is integrated within another device then a label affixed to the host shall also state, “Contains FCC ID: XXXXXX” (5) When the device is so small or for such use that it is not practicable to place the statement specified under paragraph (a) of this section on it, the information required by this paragraph shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. However, the FCC identifier or the unique identifier, as appropriate, must be displayed on the device. (2) IC Label Requirements As per IC RSS-Gen §5, the certification number shall appear as follows: IC: XXXXXX-YYYYYYYY Where: • "XXXXXX-YYYYYYYY" is the certification number • "XXXXXX" is the Certificate Holder Number (CHN), made of at most 6 alphanumeric characters (A-Z, 0-9), assigned by Industry Canada; and • "YYYYYYYY" is the Unique Product Number (UPN), made of at most 11 alphanumeric characters (A-Z, 0-9) assigned by the applicant. • Note 1: The term "IC" before the equipment certification number only signifies that the Industry Canada technical specifications were met. • Note 2: Note 1 shall be conspicuously placed in the equipment user manual. • Note 3: Permitted alphanumeric characters used in the CHN and UPN are limited to capital letters (A-Z) and digits (0-9). Other characters, such as "#", "/" or "-", shall not be used. As per RSS-Gen §5.2 Equipment Labeling: FC C Part 15.247 & IC RSS-210 R eport Number: M110720E1 Page 97 of 110 Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 Equipment subject to certification under the applicable RSS, shall be permanently labeled on each item, or as an inseparable combination. The label must contain the following information for full compliance: (a) the certification number, prefixed by the term “IC:”; (b) the manufacturer's name, trade name or brand name; and (c) a model name or number. Equipment for which a certificate has been issued is not considered certified if it is not properly labeled. The information on the Canadian label can be combined with the manufacturer’s other labeling requirements. If the device size is too small to put a label, the label can be included in the user’s manual, upon agreement with Industry Canada. FC C Part 15.247 & IC RSS-210 R eport Number: M110720E1 Page 98 of 110 Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 (3) FCC ID & IC Label Content Amp'ed RF Technology, Inc. BT31 FCC ID: X3ZBTMOD3 IC: 8828A-MOD3 Input 3VDC 60mA Made in China (4) FCC ID & IC Label on the System Model: BT31 Amp'ed RF Technology, Inc. Input 3VDC 60mA Made in China Contains Transmitter Module FCC ID: X3ZBTMOD3 IC: 8828A-MOD3 This device complies with part15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. (5) FCC ID & IC Label Location on EUT FC C Part 15.247 & IC RSS-210 R eport Number: M110720E1 Page 99 of 110 Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 Location of Label FC C Part 15.247 & IC RSS-210 R eport Number: M110720E1 Page 100 of 110

Internal Photos

Test Report

Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 FCC Part 15.247 & IC RSS-210 Report Number: M110720E1 Page 1 of 106 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 FCC Part 15.247 IC RSS-210, ISSUE 8, August 2010 TEST REPORT for the CLASS 1 OEM Bluetooth Module MODEL: BT31 FCC ID: X3ZBTMOD3 IC: 8828A-MOD3 Prepared for Amp’ed RF Technology, Inc. 1879 Lundy Ave, Ste 138, San Jose, CA 95131 Prepared by: J.H BANG Approved by: KEVIN BOTHMANN ELECTRO MAGNETIC TEST, INC. 1547 PLYMOUTH STREET MOUNTAIN VIEW, CALIFORNIA 94043 (650) 965-4000 DATE: JULY 8, 2011 REPORT APPENDICES TOTAL BODY A B C D E F G H PAGES 34 50 3 2 2 5 4 3 3 106 This report shall not be reproduced except in full, without the written approval of Electro Magnetic Test, Inc. Amp’ed RF Technology, Inc. FCC ID: X3ZBTMOD3, IC: 8828A-MOD3 FCC Part 15.247 & IC RSS-210 Report Number: M110720E1 Page 2 of 106 ELECTRO MAGNETIC TEST, INC. 1547 Plymouth Street, Mountain View, CA 94043 Tel: (650) 965-4000 Fax: (650) 965-3000 TABLE OF CONTENTS GENERAL REPORT SUMMARY ..................................................................................................................................5 SUMMARY OF TEST RESULTS ....................................................................................................................................7 TECHNICAL DESCRIPTION OF THE EUT ................................................................................................................8 1. PURPOSE ...................................................................................................................................................................9 2. ADMINISTRATIVE DATA ....................................................................................................................................10 2.1 LOCATION OF TESTING........................................................................................................................................10 2.2 TRACEABILITY STATEMENT.................................................................................................................................10 2.3 DATE TEST SAMPLE WAS RECEIVED....................................................................................................................10 2.4 DISPOSITION OF THE TEST SAMPLE......................................................................................................................10 2.5 ABBREVIATIONS AND ACRONYMS.......................................................................................................................10 3. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT.............................................................................11 3.1 EUT AND ACCESSORY LIST.................................................................................................................................11 3.2 EMI TEST EQUIPMENT........................................................................................................................................12 4. TEST SITE DESCRIPTION ...................................................................................................................................13 4.1 TEST FACILITY DESCRIPTION..............................................................................................................................13 4.2 EUT MOUNTING, BONDING AND GROUNDING.....................................................................................................13 5. TEST REQUIREMENT AND RESULT................................................................................................................14 5.1 ANTENNA REQUIREMENT....................................................................................................................................14 5.1.1 Applicable Standard ...................................................................................................................................14 5.1.2 EUT Antenna Construction........................................................................................................................14 5.2 CONDUCTED EMISSION........................................................................................................................................15 5.2.1 Applicable Standard ...................................................................................................................................15 5.2.2 Test Procedure............................................................................................................................................15 5.2.3 Test Environmental Conditions ..................................................................................................................16 5.2.4 Test Result...................................................................................................................................................16 5.3 RESTRICTED BAND AND UNWANTED EMISSIONS.................................................................................................17 5.3.1 Applicable Standard ...................................................................................................................................17 5.3.2 Test Procedure............................................................................................................................................18 5.3.3 Test Environmental Conditions ..................................................................................................................19 5.3.4 Test Result...................................................................................................................................................19 5.4 20DB BANDWIDTH TEST......................................................................................................................................21 5.4.1 Applicable Standard ...............................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Annie Cai(Operations Manager)

[email protected]408-213-9530Fax: 408-213-9533

Test Firm

Electro Magnetic Test, Inc.Jay Gandhi

[email protected]650-965-4000Fax: 650-965-3000

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	10.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations.
