XPYJODYB1BT Module

UBXDOC-465451970-3820 - R01 C2-Restricted www.u-blox.com JODY-B1 series System Integration Manual Host-based automotive modules with Dual-Mode Bluetooth® System integration manual Abstract Targeted towards hardware and software application engineers, this document describes how to integrate JODY-B1 modules in application products and explains the hardware design-in, software, component handling, regulatory compliance, and production testing. It also lists the external antennas approved for use with the module.  JODY-B1 series System Integration Manual - System integration manual UBXDOC-465451970-3820 - R01 Document information Page 2 of 44 C2-Restricted Document information Title JODY-B1 series System Integration Manual Subtitle Host-based automotive modules with Dual-Mode Bluetooth® Document type System integration manual Document number UBXDOC-465451970-3820 Revision and date R01 16-Jun-2025 Disclosure restriction C2-Restricted Document status description Draft For functional testing. Revised and supplementary data will be published later. Objective Specification Target values. Revised and supplementary data will be published later. Advance Information Data based on early testing. Revised and supplementary data will be published later. Early Production Information Data from product verification. Revised and supplementary data may be published later. Production Information Document contains the final product specification. This document applies to the following products: Product name Chipset JODY-B151-A Qualcomm QCA8695AU ☞ For information about the related hardware, software, and status of listed product types, see also the data sheet [1]. u-blox or third parties may hold intellectual property rights in the products, names, logos, and designs included in this document. Copying, reproduction, or modification of this document or any part thereof is only permitted with the express written permission of u-blox. Disclosure to third parties is permitted for clearly public documents only. The information contained herein is provided “as is” and u-blox assumes no liability for its use. No warranty, either express or implied, is given, including but not limited to, with respect to the accuracy, correctness, reliability, and fitness for a particular purpose of the information. This document may be revised by u-blox at any time without notice. For the most recent documents, visit www.u-blox.com. Copyright © u-blox AG. JODY-B1 series System Integration Manual - System integration manual UBXDOC-465451970-3820 - R01 Contents Page 3 of 44 C2-Restricted Contents 1.1 Overview ........................................................................................................................................................ 5 1.2 Module architecture ................................................................................................................................... 5 2.1 Power supply interface ............................................................................................................................... 6 2.2 Antenna interfaces ..................................................................................................................................... 7 2.2.1 RF pins and connectors ..................................................................................................................... 8 2.2.2 Approved antenna designs ............................................................................................................... 8 2.2.3 Integrated antennas .......................................................................................................................... 8 2.2.4 External antennas .............................................................................................................................. 8 2.3 System function interfaces ...................................................................................................................... 9 2.3.1 Power-up sequence ............................................................................................................................ 9 2.3.2 Reset ..................................................................................................................................................... 9 2.3.3 Power-off sequence .......................................................................................................................... 10 2.3.4 Wake-up signals ................................................................................................................................ 10 2.3.5 Power states ...................................................................................................................................... 10 2.4 Host interfaces .......................................................................................................................................... 10 2.4.1 High-speed UART interface ............................................................................................................ 10 2.4.2 SPI interface ...................................................................................................................................... 12 2.4.3 PCM/I2S audio interface ................................................................................................................. 12 2.5 External coexistence interface ............................................................................................................... 13 2.6 JTAG ............................................................................................................................................................ 13 2.7 Other remarks ............................................................................................................................................ 13 2.7.1 Unused pins .............................................................................................................................…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 5, 2026 FCC ID: XPYJODYB1 RE: Covered listed Attestation Part 2.911(d)(5)(i) Filing u-blox AG (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. u-blox AG (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. Or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. RE: Attestation Statements Part 2.911(d)(5)(ii) Filing u-blox AG (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Applicant : u-blox AG Address : Zuercherstrasse 68, Thalwil, Ch-8800 Switzerland Signature : _________________________________ Name and Job Title : Filip Kruzela, Certification Manager E-mail : [email protected] Tel. : +46733207170

Certification designating a U.S. Agent for service of process: As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. In either scenario, the designation of the U.S. agent for service of process should be provided as an attachment to the equipment authorization application. The applicant must provide a written certification, which must: i. Be signed by both the applicant and designated agent for service of process, if the agent is different from the applicant. ii. Acknowledge the applicant’s consent and the designated agent’s obligation to accept service of process. iii. Provide a physical U.S. address and email for the designated agent. iv. Acknowledge the applicant’s acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Unofficial information provided by FCC personnel on February 14, 2023, via the monthly call with the TCB Council: The Agent for Process of Service: • cannot be a TCB or affiliated with a TCB (e.g. could not be a person who works for a TCB or a company that owns or is owned by the TCB) • cannot be a [FCC recognised] Lab or affiliated with a test lab (e.g. could not be a person who works for a Lab or a company that owns or is owned by the Lab) • Agent can be Individual Entity or a Company Entity • Agent Entity must be located in US, US address/phone • Entity acting as Agent must have FRN (best practice, put FRN on Agent Letter) • Agent letter does not have to be FCC ID specific, can be general Agent for Grantee For devices being marketed or for which marketing has ceased for less than 1 year, if the Agent for Process of Service changes, then for every TC Number the TCB must request the FCC to put application into Audit Mode and Agent Letter needs to be updated (superseded). NOTE: The U.S. Agent for Service of Process should not be confused with the authorized agent used for signing the 731 form, other cover letters within the application, and/or the agent who may interface with the TCB. U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 This letter is to confirm that we (“t he Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: June 4, 2025 Signed by (Printed Name/Title): Nathan Grinager / Co-President The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: u-blox AG Grantee FRN: 0019077858 Grantee Code: XPY Contact Name: Filip Kruzela Street Address: Zuercherstrasse 68, Thalwil Ch-8800, Switzerland City/Province/Zip: Thalwil Ch-8800 Telephone No: +46 40 630 71 70 Email: [email protected] Applicant Signature: Date: June 4, 2025 Signed by (Printed Name/Title): Filip Kruzela, Certification Manager

1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 DD CC BB AA A.1 By 2024-12-03 Rev.DateDescription Schematic/Assembly Revision okoninitial release B.12025-07-01okonadjustments L6,L7,C29; PCB adjustments B.22025-11-12okonadjustments L3,R19,C29 Author: okon Release Date: 2025-11-12 Project: JODY-B1 Sch Num: JODY-B1_Top.SchDocQCA8695AU, Bluetooth 5.4 module 1 / 5 Page: Part Number: JODY-B151-01A Team: mod-sho Berlin PCB: UBXH60-0001211 PCBA: Revision: B.2 ZU_JB1 Size: A3 C3- Confidential U_JODY-B1_Design JODY-B1_Design.SchDoc U_JODY-B1_PowerSupply JODY-B1_PowerSupply.SchDoc U_JODY-B1_RF JODY-B1_RF.SchDoc U_JODY-B1_History JODY-B1_History.SchDoc

Request for Confidentiality Date: May 5, 2026 Federal Communications Commission Authorization and Evaluation Division Subject: Request for confidentiality- Permanent Confidentiality Request FCC ID: XPYJODYB1 To whom it may concern: Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. 1. Schematic diagram 2. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Applicant : u-blox AG Address : Zuercherstrasse 68, Thalwil, Ch-8800 Switzerland Signature : _________________________________ Name and Job Title : Filip Kruzela, Certification Manager E-mail : [email protected] Tel. : +46733207170

Agent Authorization Letter Date: May 5, 2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: XPYJODYB1 Product Name: BT Module To whom it may concern: We, the undersigned, hereby authorize the following person to act as our agent in the preparation and submission of an application for equipment authorization in accordance with the FCC Rules and Regulations. Sporton International Inc. Address : No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Name : Leo Huang Job Title : VP e-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 CFR § 1.2002(b), is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862. This authorization also includes the authority to complete FCC Form 731 on our behalf and to sign the application as an authorized agent. Sincerely, Applicant : u-blox AG Address : Zuercherstrasse 68, Thalwil, Ch-8800 Switzerland Signature : _________________________________ Name and Job Title : Filip Kruzela, Certification Manager E-mail : [email protected] Tel. : +46733207170

UBXDOC-885269510-199737 C3-Confidential 1/2 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Part 15 Single-Modular Transmitter Approval Company name: u-blox AG FCC ID: XPYJODYB1 FCC Part 15 Certification To whom it may concern: Herewith we state that the requirements according to FCC Part 15.212 are met and the module qualifies for a single modular transmitter approval. In CFR Title 47 Chapter I Subchapter A Part 15 Subpart C Section 15.212 there are eight numbered requirements that our device complies with: 1. The modular transmitter must have its own RF shielding The module has its RF-parts enclosed by a shield cover soldered onto the module ground plane. See external photos. 2. The modular transmitter must have buffered modulation/data inputs The module does not have modulation inputs. The electrical interface available to the module integrator consists of Power supply, UART, SPI and I/O signals. The interface signals are internally buffered by the module System on Chip and cannot affect the modulation. Detailed instructions on how to connect these interface signals are given in the integration manual. 3. The modular transmitter must have its own power supply regulation The module SoC (System on Chip) has its own internal voltage regulators. In case the supply voltage fluctuates internal voltages will be kept unaffected. 4. The modular transmitter must comply with the antenna requirements of Section 15.203, 15.204(b) and 15.204(c) The RF-port of module version JODY-B151-01A is available at a solder land and the antenna trace reference design guides the module integrator how to connect this solder land to U.FL connectors. 5. The modular transmitter must be tested in a stand-alone configuration The module was soldered onto the evaluation board EVK-JODY-B1 and tested in a stand-alone configuration. 6. The modular transmitter must be labelled with its own FCC ID number The module is labelled with its own FCC ID number. Registered office: u-blox AG Zürcherstrasse 68 8800 Thalwil Switzerland [email protected] [email protected] UBXDOC-885269510-199737 C3-Confidential 2/2 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The required FCC rules has been fulfilled and all instructions for maintaining compliance has been clearly stated in the user manual 8. The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. JODY-B151-01A complies with the RF exposure limits when integrated into host devices categorized as mobile and/or fixed. See separate document for RF exposure calculations. Sincerely, _______________________________ Filip Kruzela, Certification Manager, u-blox AG

PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 1 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : 24/Jul/2026 Report Version : 02 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 2 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : 24/Jul/2026 Report Version : 02 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 3 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : 24/Jul/2026 Report Version : 02 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 5 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : 24/Jul/2026 Report Version : 02 Ant. 1: Molex / 146153 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 6 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : 24/Jul/2026 Report Version : 02 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 7 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : 24/Jul/2026 Report Version : 02 ─────THE END───── Ant. 2 : Linx / ANT-DB1-RAF

RE: Certification Application HVIN : JODY-B151-01A, FCC ID : XPYJODYB1, IC : 8595A-JODYB1 Label location information for JODY-B1 series module The product label is affixed on to the module shield cover as shown in Figure 1. The size of the label is 17 x 11 mm and contains the following information: • A Data Matrix formatted bar code, with a unique serial number • Date of unit production formatted YY/WW (year/week) • Major and minor product version info • Product marketing name (e.g. JODY-B151-01A) Figure 1: Label of the JODY-B151-01A module Figure 2: Actual size of the JODY-B1 modules identifier marking (17 x 11 mm) Figure 3: Label location of the JODY-B1 modules Registered office: u-blox AG Zürcherstrasse 68 8800 Thalwil Switzerland Company number: CH-020.3.020.161-7 [email protected] [email protected]

PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 1 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : 15/Jun/2026 Report Version : 01 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 2 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : 15/Jun/2026 Report Version : 01 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 3 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : 15/Jun/2026 Report Version : 01 PHOTOGRAPHS OF EUT EP631105 Sporton International Inc. Page No. : 4 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : 15/Jun/2026 Report Version : 01 ─────THE END─────

Radio Exposure Evaluation Report Report No. : FA631105 TEL : 886-3-327-3456 Page Number : 1 of 10 FAX : 886-3-327-0973 Issued Date : Jul. 16, 2026 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XPYJODYB1 Radio Exposure Evaluation Report FCC ID : XPYJODYB1 Equipment : BT Module Brand Name : u-blox Model Name : JODY-B151-01A Applicant : u-Blox AG Zü rcherstrasse 68, 8800 Thalwil Switzerland Manufacturer : u-Blox AG Zü rcherstrasse 68, 8800 Thalwil Switzerland Standard : 47 CFR FCC Part 2 Subpart J, section 2.1091 The product was received on Mar. 20, 2026, and testing was started from Apr. 17, 2026 and completed on Apr. 17, 2026. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in 47 CFR FCC Part 2 Subpart J, section 2.1091 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Jackson Tsai __________________________________________ SDoC by: XXXXX SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) Radio Exposure Evaluation Report Report No. : FA631105 TEL : 886-3-327-3456 Page Number : 2 of 10 FAX : 886-3-327-0973 Issued Date : Jul. 16, 2026 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XPYJODYB1 Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 5 1.3 Testing Location ..................................................................................................................................... 5 2 MAXIMUM PERMISSIBLE EXPOSURE ............................................................................................... 6 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 6 2.2 RF Exposure Exempt Measurement ...................................................................................................... 7 2.3 Multiple RF Sources Exposure ............................................................................................................... 8 2.4 MPE Calculation Method ........................................................................................................................ 9 2.5 Calculated Result and Limit .................................................................................................................. 10 Photographs of EUT V01 Radio Exposure Evaluation Report Report No. : FA631105 TEL : 886-3-327-3456 Page Number : 3 of 10 FAX : 886-3-327-0973 Issued Date : Jul. 16, 2026 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XPYJODYB1 History of this test report Report No. Version Description Issued Date FA631105 01 Initial issue of report Jul. 16, 2026 Radio Exposure Evaluation Report Report No. : FA631105 TEL : 886-3-327-3456 Page Number : 4 of 10 FAX : 886-3-327-0973 Issued Date : Jul. 16, 2026 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XPYJODYB1 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: None Reviewed by: Ben Tseng Report Producer: Michelle Tsai Radio Exposure Evaluation Report Report No. : FA631105 TEL : 886-3-327-3456 Page Number : 5 of 10 FAX : 886-3-327-0973 Issued Date : Jul. 16, 2026 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: XPYJODYB1 1 General Description 1.1 Information 1.1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type Bluetooth 2400-2483.5 2402-2480 BR / EDR: FHSS (GFSK / π/4-DQPSK / 8DPSK) LE: DSSS (GFSK) 1.1.2 Antenna Information Ant. Brand Name Model Name Ant. Type Connector Gain (dBi) 1 Molex 146153 Flex (FPC) PCB I-Pex 3 2 Linx ANT-DB1-RAF Dipole SMA 4.1 Note 1: The EUT has two antennas. Note 2: The antenna mentioned above will not be sold with the EUT in the market. For BT function: For IEEE 802.15.1 Bluetooth mode (1TX/1RX) Ant. 1 or Ant.2 could transmit/receive. 1.2 Applicable Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⬧ 47 CFR FCC Part 2 Subpart J, section 2.1091 ⬧ KDB 447498 D04 Interim General RF Exposure Guidance v01 The following reference test guidance is not within the scope of accreditation of TAF. ⬧ 47 CFR Part 1.1307 ⬧ 47 CFR Part 1.1310 1.3 Testing Location Test Lab.：Sporton International Inc. Hsinhua Laboratory Hsinhua ADD: No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) (TAF: 3785) TEL: 886-3-327-3456 FAX: 886-3-327-0973 Test site Designation No. TW3785 with FCC. Wenhua 3rd. ADD: No. 58, Aly. 75, Ln. 564, Wenhua 3rd Rd., Guishan Dist. Taoyuan City 333, Taiwan (R.O.C.) (TAF: 3785) TEL: 886-3-327-0868 Test site Designation …

Text truncated - open the document above for the full version.

APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E FLEX CABLE BALANCE ANTENNA APPLICATION SPECIFICATION SHEET No. J1 EC No: 729862 1 of 31 DATE: 2022/11/25 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461530100 Liu Hai Andy Zhang Chris Zhong TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC TITLE WIFI 6E FLEX CABLE BALANCE ANTENNA TABLE OF CONTENTS 1.0 SCOPE 2.0 PRODUCT DESCRIPTION 3.0 APPLICABLE DOCUMENTS 4.0 ANTENNA PERFORMANCE 5.0 ASSEMBLY GUIDELINE 6.0 RF PERFORMANCE AS A FUNCTION OF IMPLEMENTATION 7.0 THE ANTENNA PERFORMANCE VARIATION WITH CABLE LENGTH 8.0 OTHER MOLEX ANTENNA PRODUCTS 9.0 CHANGE HISTORY APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E FLEX CABLE BALANCE ANTENNA APPLICATION SPECIFICATION SHEET No. J1 EC No: 729862 2 of 31 DATE: 2022/11/25 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461530100 Liu Hai Andy Zhang Chris Zhong TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC WIFI 6E FLEX CABLE BALANCE ANTENNA 1.0 SCOPE This specification describes the antenna application and surrounding. The information in this document is for reference and benchmark purposes only. The user is responsible for validating antenna rf performance based on the user’s actual implementation. Antenna illustrations in this document are generic representations. They are not intended to be an image of any antenna listed in the scope. 2.0 PRODUCT DESCRIPTION 2.1 PRODUCT NAME AND SERIES NUMBER (S) Product name: WIFI 6E flex cable balance antenna Series Number: 146153 2.2 DESCRIPTION Series 146153 is a balanced, dipole-type, high efficiency antenna for 2.4/5/6 GHz applications, including WiFi 6E, Bluetooth, Zigbee and others. This antenna is made from poly flexible material with small size 35*9*0.1mm and has double-sided adhesive tape for easy “peel and stick” mounting. This balanced antenna with ground plane independent design offers various cable length options for ease of integration into various devices. 2.3 PRODUCT STRUCTURE INFORMATION Please refer to PS-1461530100 for full information. ANTENNA 3D VIEW APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E FLEX CABLE BALANCE ANTENNA APPLICATION SPECIFICATION SHEET No. J1 EC No: 729862 3 of 31 DATE: 2022/11/25 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461530100 Liu Hai Andy Zhang Chris Zhong TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 3.0 APPLICABLE DOCUMENTS DOCUMENT NUMBER DESCRIPTION Sale Drawing (SD) SD-1461530050 Mechanical Dimension of the product SD-1461531050 Product Specification (PS) PS-1461530100 Product Specification Packing Drawing (PK) PK-1461530100 Product packaging specifications 4.0 ANTENNA PERFORMANCE 4.1 RF TEST CONDITIONS All measurements are done of the antenna mounted on a PC/ABS material block of 1.5mm thickness with VNA Agilent E5071C and Over-The-Air (OTA) chamber. All measurements in this document are done with the part no.1461530100 with a cable length of 100mm. FIGURE4.1.1 ANTENNA LOADED WITH PC/ABS BLOCK OF 1.5 MM THICKNESS APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E FLEX CABLE BALANCE ANTENNA APPLICATION SPECIFICATION SHEET No. J1 EC No: 729862 4 of 31 DATE: 2022/11/25 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461530100 Liu Hai Andy Zhang Chris Zhong TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC FIGURE4.1.2 ANTENNA LOADED WITH PC/ABS BLOCK OF 1.5 MM THICKNESS WITH VNA DUT APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E FLEX CABLE BALANCE ANTENNA APPLICATION SPECIFICATION SHEET No. J1 EC No: 729862 5 of 31 DATE: 2022/11/25 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461530100 Liu Hai Andy Zhang Chris Zhong TEMPLATE FILENAME: APPLICA…

Text truncated - open the document above for the full version.
