XPYTOBYL200GSM/UMTS/LTE Data Module

u-blox AG

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Oct 22, 2014
Application Purpose: Original Equipment
Date of Application: Oct 21, 2014
Equipment Note: GSM/UMTS/LTE Data Module
Frequency Range: 2502.50000000 - 2567.50000000
Company: u-blox AG
Country: Switzerland

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TOBY-L2 and MPCI-L2 series LTE/DC-HSPA+/EGPRS modules System Integration Manual Abstract This document describes the features and the system integration of TOBY-L2 and MPCI-L2 series multi-mode cellular modules. These modules are a complete and cost efficient LTE/3G/2G solution offering up to 150 Mb/s download and 50 Mb/s upload data rates, covering up to six LTE bands, up to five WCDMA/DC-HSPA+ bands and four GSM/EGPRS bands in the compact TOBY LGA form factor of TOBY-L2 modules or in the industry standard PCI Express Mini Card form factor of MPCI-L2 modules. TOBY-L2 series www.u-blox.com UBX-13004618 - R04 MPCI-L2 series TOBY-L2 and MPCI-L2 series - System Integration Manual UBX-13004618 - R04 Page 2 of 141 Document Information Title TOBY-L2 and MPCI-L2 series Subtitle LTE/DC-HSPA+/EGPRS modules Document type System Integration Manual Document number UBX-13004618 Revision and date R04 30-Sep-2014 Document status Advance Information Document status explanation Objective Specification Document contains target values. Revised and supplementary data will be published later. Advance Information Document contains data based on early testing. Revised and supplementary data will be published later. Early Production Information Document contains data from product verification. Revised and supplementary data may be published later. Production Information Document contains the final product specification. This document applies to the following products: Name Type number Firmware version PCN / IN TOBY-L200 TOBY-L200-00S-00 09.40 UBX-14040967 TOBY-L210 TOBY-L210-00S-00 09.40 UBX-14040967 MPCI-L200 MPCI-L200-00S-00 09.34 UBX-14040967 MPCI-L210 MPCI-L210-00S-00 09.34 UBX-14040967 u-blox reserves all rights to this document and the information contained herein. Products, names, logos and designs described herein may in whole or in part be subject to intellectual property rights. Reproduction, use, modification or disclosure to third parties of this document or any part thereof without the express permission of u-blox is strictly prohibited. The information contained herein is provided “as is” and u-blox assumes no liability for the use of the information. No warranty, either express or implied, is given, including but not limited, with respect to the accuracy, correctness, reliability and fitness for a particular purpose of the information. This document may be revised by u-blox at any time. For most recent documents, please visit www.u-blox.com. Copyright © 2014, u-blox AG u-blox ® is a registered trademark of u-blox Holding AG in the EU and other countries. PCI, PCI Express, PCIe, and PCI-SIG are trademarks or registered trademarks of PCI-SIG. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. ARM ® is a registered trademark of ARM Limited in the EU and other countries. All other registered trademarks or trademarks mentioned in this document are property of their respective owners. TOBY-L2 and MPCI-L2 series - System Integration Manual UBX-13004618 - R04 Advance Information Preface Page 3 of 141 Preface u-blox Technical Documentation As part of our commitment to customer support, u-blox maintains an extensive volume of technical documentation for our products. In addition to our product-specific technical data sheets, the following manuals are available to assist u-blox customers in product design and development.  AT Commands Manual: This document provides the description of the AT commands supported by the u-blox cellular modules.  System Integration Manual: This document provides the description of u-blox cellular modules’ system from the hardware and the software point of view, it provides hardware design guidelines for the optimal integration of the cellular modules in the application device and it provides information on how to set up production and final product tests on application devices integrating the cellular modules.  Application Note: These documents provide guidelines and information on specific hardware and/or software topics on u-blox cellular modules. See Related documents for a list of Application Notes related to your Cellular Module. How to use this Manual The TOBY-L2 and MPCI-L2 series System Integration Manual provides the necessary information to successfully design and configure the u-blox cellular modules. This manual has a modular structure. It is not necessary to read it from the beginning to the end. The following symbols are used to highlight important information within the manual: An index finger points out key information pertaining to module integration and performance. A warning symbol indicates actions that could negatively impact or damage the module. Questions If you have any questions about u-blox Cellular Integration:  Read this manual carefully.  Contact our information service on the homepage http://www.u-blox.com/ Technical Support Worldwide Web Our website (http://www.u-blox.com/) is a rich pool of information. Product information, technical documents can be accessed 24h a day. By E-mail Contact the closest Technical Support office by email. Use our service pool email addresses rather than any personal email address of our staff. This makes sure that your request is processed as soon as possible. You will find the contact details at the end of the document. Helpful Information when Contacting Technical Support When contacting Technical Support, have the following information ready:  Module type (TOBY-L200) and firmware version  Module configuration  Clear description of your question or the problem  A short description of the application  Your complete contact details TOBY-L2 and MPCI-L2 series - System Integration Manual UBX-13004618 - R04 Advance Information Contents Page 4 of 141 Contents Preface ................................................................................................................................ 3 Contents ......................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Registergericht  registered in:Vorstand  Board of Directors:7 layers AG, Borsigstrasse 11 Ratingen, HRB 3264Dr. Wolfgang Dahm40880 Ratingen, Germany Aufsichtsratsvorsitzende  Dr. Hans-Jürgen MeckelburgPhone: +49 (0) 2102 749 0 Chairman of the Supervisory Board:Fax: +49 (0) 2102 749 350 Dr. Sabine Grobeckerwww.7Layers.com Patrick Lomax 23 May 2014 Phone +49 (0) 2102 749 331 Fax +49 (0) 2102 749 350 Email: [email protected] request for a modular approval - FCC ID: XPYTOBYL200 Dear Application Examiner, the module “TOBY-L200” is seeking FCC authorization as a modular transmitter. The requirement of the FCC part 15.212 are met. The following requirements are fulfilled: 1. The modular transmitter must have its own RF shielding The radio portion of the module has its own RF shielding. 2. The modular transmitter must have buffered modulation/data inputs The module has a memory management unit inside of the IC. It buffers the data inputs. 3. The modular transmitter must have its own power supply regulation The IC contains an own voltage regulation. In case of changes in the supply voltage VCC (for example caused by temperature changes or other effects), the internal voltage will be stabilized. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c Not applicable to licensed transmitters. Module is professionally installed and antenna gain is listed in teh installation instructions. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. FCC Federal Communications Commission - 2 - 6. The modular transmitter must be labelled with its own FCC ID number The Module is labelled with its own FCC ID. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. 8. The modular transmitter must comply with any applicable RF exposure requirements. This device has been assessed for mobile use and complies with the limits. Please contact us if you have any additional questions. Best Regards, Patrick Lomax Project Manager 7layers AG

RF Exposure Info

Test Laboratory: Borsigstrasse 11 Germany 7Layers AG 40880 Ratingen Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender  Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Dr. H. Ansorge RF Exposure and Maximum ERP/EIRP Assessment For TOBY‐L200 GSM/UMTS Module FCC ID: XPYTOBYL200 IC: 8595A‐TOBYL200 Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 2 of 12 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 1 Administrative Data 4 1.1 Testing Laboratory 4 1.2 Project Data 4 1.3 Applicant Data 4 1.4 Manufacturer Data 4 2 Test object Data 5 2.1 General EUT Description 5 2.2 EUT Main components 5 2.3 Ancillary Equipment 5 2.4 Auxiliary Equipment 5 2.5 Operating Modes 6 3 Evaluation Results 7 3.1 Maximum ERP / EIRP 7 3.2 RF Exposure Evaluation for Module 8 3.3 RF Exposure Evaluation for multiple transmitters in co-location 10 Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 4 of 12 1 Administrative Data 1.1 Testing Laboratory Company Name: 7Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716. The test facility is also accredited by the following accreditation organisation: Laboratory accreditation no.: DAkkS D‐PL‐12140‐01‐01 Responsible for Accreditation Scope:Dipl.‐Ing. Bernhard Retka Dipl.‐Ing. Robert Machulec Dipl.‐Ing. Andreas Petz Dipl.‐Ing. Marco Kullik Report Template Version: 2014‐05‐15 1.2 Project Data Responsible for assessment and report:Mr. Patrick Lomax Date of Report: 2014‐09‐23 1.3 Applicant Data Company Name: u‐blox AG Address: Zürcherstrasse 68, CH-8800 Thalwil Switzerland Contact Person: Giulio Comar 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 5 of 12 2 Test object Data 2.1 General EUT Description Equipment under Test TOBY‐L200 Module Type Designation: TOBY‐L200 Kind of Device: GPRS/EDGE MSC GSM/UMTS/LTE DataModule GPRS Multi‐slot class 12 FCC ID: XPYTOBYL200 IC Number: 8595A‐TOBYL200 General product description: The EUT is Cellular radio module supporting GSM/GPRS/WCDMA/HSDPA/HSUPA/LTE 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short DescriptionEquipment under TestType DesignationSerial No.HW Status SW Status EUT A Code: DE1015003AU12 TOBY‐L200L200352255060018284192BA0 09.41 NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of this test report, ancillary equipment is defined as equipment which is used in conjunction with the EUT to provide operational and control features to the EUT. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Ancillary Equipment can influence the test results. Short Description Equipment under Test Type Designation HW StatusSW StatusSerial no. FCC ID N/A ‐ 2.4 Auxiliary Equipment For the purposes of this test report, auxiliary equipment is defined as equipment which is used temporarily to enable operational and control features especially used for the tests of the EUT which is not used during normal operation or equipment that is used during the tests in combination with the EUT but is not subject of this test report. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Auxiliary Equipment can influence the test results. Short Description Equipment under Test Type Designation Serial no.HW StatusSW Status FCC ID N/A – Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 6 of 12 2.5 Operating Modes This chapter describes the operating modes of the EUTs used for testing. Op. Mode Description of Operating ModesRemarks Op‐mode 1 EUT transmitting in standalone configurationAntenna‐to‐person distance > 20cm Op‐mode 2 EUT transmitting in the 850 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 3 EUT transmitting in the 1900 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 4 EUT transmitting in the 850 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 5 EUT transmitting in the 1900 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 6 EUT transmitting in the 850 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 7 EUT transmitting in the 1900 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 8 EUT transmitting in the 700 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 9 EUT transmitting in the 700 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 10 EUT transmitting in the 700 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 11 EUT transmitting in the 1700 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 12 EUT transmitting in the 1700 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 13 EUT transmitting in the 1700 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 14 EUT transmitting in the 2500 MHz …

Text truncated - open the document above for the full version.

Test Report

Final Report on TOBY L200 Data Module FCC ID: XPYTOBYL200 IC:8595A-TOBYL200 MDE_UBLOX_1408_FCCa Rev2 according to FCC Part 22, Subpart H Part 24, subpart E FCC Part 27 Subpart C Re port Reference: October 17, 2014Date: Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender  Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Dr. H. Ansorge Reference: MDE_UBLOX_1408_FCCa Rev2 according to FCC Part 22, Subpart H Part 24, subpart E FCC Part 27 Subpart C 1Administrative Data 1.1Project Data Patrick Lomax Project Responsible: Date Of Test Re port: Date of first test: 2014/10/17 2014/07/14 2014/10/14 Date of last test: 1.2Applicant Data Company Name:u-blox AG Zürcherstrasse 68, CH-8800 Thalwil Street: SwitzerlandCountry: Contact Person:Mr. Giulio Comar Certification ManagerFunction: Wireless R&D centerDepartment: +41 44 722 7462Phone: +41 44 722 7447Fax: [email protected]: 1.3Test Laboratory Data The following list shows all places and laboratories involved for test result generation: 7 layers DE Company Name :7 layers AG Street :Borsigstrasse 11 City :40880 Ratingen Country :Germany Contact Person :Mr. Michael Albert Phone :+49 2102 749 201 Fax :+49 2102 749 444 E Mail :[email protected] Laboratory Details Accreditation InfoLab IDIdentification DAkkS-Registration no. D-PL-12140-01-01Radiated EmissionsLab 1 DAkkS-Registration no. D-PL-12140-01-01Radio LabLab 2 1.4Signature of the Testing Responsible patrick lomax responsible for tests performed in: Lab 1, Lab 2 Page 2 of 151 Reference: MDE_UBLOX_1408_FCCa Rev2 according to FCC Part 22, Subpart H Part 24, subpart E FCC Part 27 Subpart C 2.2Detailed Description of OUT Samples Sample : AP11 OUT IdentifierTOBY-L200 Sample DescriptionRF Sample Serial No.352251060022016 HW Status192BA0 SW Status09.41 Date of Receipt2014/08/05 Low VoltageLow Temp.3.3 V-20 °C High Temp.High Voltage4.4 V55 °C Normal Temp.Nominal Voltage3.8 V25 °C Sample : AQ08 OUT IdentifierTOBY-L200 Sample DescriptionStandard Sample Serial No.352251060021687 HW Status192BA0 SW Status09.37 Date of Receipt2014/07/31 Low VoltageLow Temp.3.3 V-20 °C High Temp.High Voltage4.4 V55 °C Normal Temp.Nominal Voltage3.8 V25 °C Sample : AQ09 OUT IdentifierTOBY-L200 Sample DescriptionStandard Sample Serial No.352251060021687 HW Status192BA0 SW Status09.38_ENG01 Date of Receipt2014/08/12 Page 4 of 151 Reference: MDE_UBLOX_1408_FCCa Rev2 according to FCC Part 22, Subpart H Part 24, subpart E FCC Part 27 Subpart C Sample : AX05 OUT IdentifierTOBY-L200 Sample DescriptionStandard Sample Serial No.352251060022248 HW Status192BA0 SW Status09.32 Date of Receipt2014/07/10 Low VoltageLow Temp.3.3 V-20 °C High Temp.High Voltage4.4 V55 °C Normal Temp.Nominal Voltage3.8 V25 °C Sample : AX07 OUT IdentifierTOBY-L200 Sample DescriptionStandard Sample Serial No.352251060022248 HW Status192BA0 SW Status09.35 Date of Receipt2014/07/15 Low VoltageLow Temp.3.3 V-20 °C High Temp.High Voltage4.4 V55 °C Normal Temp.Nominal Voltage3.8 V25 °C Sample : AX08 OUT IdentifierTOBY-L200 Sample DescriptionStandard Sample Serial No.352251060022248 HW Status192BA0 SW Status09.37 Date of Receipt2014/07/31 Low VoltageLow Temp.3.3 V-20 °C High Temp.High Voltage4.4 V55 °C Normal Temp.Nominal Voltage3.8 V25 °C Page 5 of 151 Reference: MDE_UBLOX_1408_FCCa Rev2 according to FCC Part 22, Subpart H Part 24, subpart E FCC Part 27 Subpart C Sample : BD11 OUT IdentifierTOBY-L200 Sample DescriptionStandard Sample Serial No.352251060043772 HW Status192BA04 SW Status09.41 Date of Receipt2014/08/22 2.3OUT Features Supported Features for OUT:TOBY-L200 DesignationDescriptionSupported Value(s) Features for scope: AT-CMD_v1 A Features for scope: FCC_v2 ACThe OUT is powered by or connected to AC Mains EDGE850EUT supports EDGE in the band 824 MHz - 849 MHz EDGE1900EUT supports EDGE in the band 1850 MHz - 1910 MHz FDD2EUT supports UMTS FDD2 in the band 1850 MHz - 1910 MHz FDD4EUT supports UMTS FDD4 in the band 1710 MHz - 1755 MHz FDD5EUT supports UMTS FDD5 in the band 824 MHz - 849 MHz GSM850EUT supports GSM850 band 824MHz - 849MHz HSDPA-FDD2EUT supports UMTS FDD2 HSDPA in the band 1850 MHz - 1910 MHz HSDPA-FDD4EUT supports UMTS FDD4 HSDPA in the band 1710 MHz - 1755 MHz HSDPA-FDD5EUT supports UMTS FDD5 HSDPA in the band 824 MHz - 849 MHz HSUPA-FDD2EUT supports UMTS FDD2 HSUPA in the band 1850 MHz - 1910 MHz HSUPA-FDD4EUT supports UMTS FDD4 HSUPA in the band 1710 MHz - 1755 MHz HSUPA-FDD5EUT supports UMTS FDD5 HSUPA in the band 824 MHz - 849 MHz PCS1900EUT supports PCS1900 band 1850MHz - 1910MHz Page 6 of 151 Reference: MDE_UBLOX_1408_FCCa Rev2 according to FCC Part 22, Subpart H Part 24, subpart E FCC Part 27 Subpart C 2.4Setups used for Testing For each setup a relation is given to determine if and which samples and auxiliary equipment is used. The left side list all OUT samples and the right side lists all auxiliary equipment for the given setup. Sample No.Sample DescriptionAE No.AE Description Setup No.List of OUT samplesList of auxiliary equipment S01_AP11 AP11RF SampleSample: S01_AQ08 AQ08Standard SampleSample: S01_AQ09 AQ09Standard SampleSample: S01_AX05 AX05Standard SampleSample: S01_AX07 (AX07) AX07Standard SampleSample: S01_AX08 AX08Standard SampleSample: S01_BD11 BD11Standard SampleSample: 3Results 3.1General Available at the test laboratory. The results of the inspection are described on the following pages, where 'Conformity' or 'Passed' means that the certification criteria were verified and that the tested device is conform to the applied stand…

Text truncated - open the document above for the full version.

Test Report

Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender  Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Dr. H. Ansorge FCC Measurement/Technical Report on TOBY-L210 GSM/UMTS/HSPA/LTE Data Module FCC ID: XPYTOBYL210 IC:8595A-TOBYL210 Report Reference: MDE_UBLOX_1409_FCCb according to FCC Part 22, Subpart H Test report Reference: MDE_UBLOX_1409_FCCb FCC Part 22, Subpart H Page 2 of 47 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 5 1 Administrative Data 6 1.1 Testing Laboratory 6 1.2 Project Data 6 1.3 Applicant Data 6 1.4 Manufacturer Data 6 2 Test object Data 7 2.1 General EUT Description 7 2.2 EUT Main components 8 2.3 Ancillary Equipment 8 2.4 Auxiliary Equipment 8 2.5 EUT Setups 9 2.6 Operating Modes 9 2.7 Special software used for testing 10 2.8 Product labeling 10 3 Test Results 11 3.1 RF Power Output 11 3.2 Frequency stability 14 3.3 Spurious emissions at antenna terminals 17 3.4 Emission and Occupied Bandwidth 19 3.5 Band edge compliance 21 3.6 Power to Average Ratio 23 4 Test Equipment 24 5 Photo Report 27 6 Setup Drawings 28 7 Annex measurement plots 30 7.1 RF Power Output §2.1046, §22.913 30 7.2 Peak to Average Ratio RSS-132, §5.4 32 7.3 Spurious emissions at antenna terminals §2.1051, §22.917 34 7.4 Emission and Occupied Bandwidth §2.1049, §22.917 36 7.5 Band edge compliance §2.1053, §22.917 44 Test report Reference: MDE_UBLOX_1409_FCCb FCC Part 22, Subpart H Page 3 of 47 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for a GSM/WCDMA/LTE cellular radiotelephone device. This report covers only the LTE portion of this device. Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 0 to 69. The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification § 2.1046 Measurement required: RF power output § 2.1049 Measurement required: Occupied bandwidth § 2.1051 Measurement required: Spurious emissions at antenna terminals § 2.1053 Measurement required: Field strength of spurious radiation* § 2.1055 Measurement required: Frequency stability § 2.1057 Frequency spectrum to be investigated *Covered by external report. Part 22, Subpart C – Operational and Technical Requirements § 22.355 Frequency tolerance Part 22, Subpart H – Cellular Radiotelephone Service § 22.913 Effective radiated power limits § 22.917 Emission limitations for cellular equipment Additional documents Note: ANSI TIA-603-C-2004 Test report Reference: MDE_UBLOX_1409_FCCb FCC Part 22, Subpart H Page 4 of 47 Correlation of measurement requirements for Cellular Equipment from FCC and IC FCC Rule / IC Standard Test Case 22 / RSS-132 24 / RSS-133 27 / RSS-139 Applicable Bands: GSM 850 FDD 5 E-FDD5 Applicable Bands: GSM 1900 FDD 2 E-FDD 2 Applicable Bands: FDD 4 E-FDD 4 E-FDD 7 E-FDD 17 Effective (isotropic) Radiated Power §2.1046 §22.913 AV ERP !! RSS-GEN, §4.8 RSS-132, §5.4 AV EIRP Power §2.1046 §24.232 Peak EIRP Power (RMS- equivalent calibrated)) RSS-GEN, §4.8 RSS-133, §6.4 AV EIRP Power §2.1046 §27.50 (d) AV EIRP Power RSS-GEN, §4.8 RSS-139; §6.4 AV EIRP Power Occupied Bandwidth §2.1049 RSS-GEN §4.6 §2.1049 RSS-GEN §4.6 §2.1049 RSS-GEN §4.6 “Spuri” at Antenna Terminal §2.1051 §22.917 RSS-GEN, §4.9 RSS-132, §5.5 §2.1051 §24.238 RSS-GEN, §4.9 RSS-132, §6.5 §2.1051 §27.5 (h) RSS-GEN, §4.9 RSS-139, §6.5 Band Edge compliance §2.1051 §22.917 RSS-GEN, §4.6 §2.1051 §24.238 RSS-GEN, §4.6 §2.1051 §27.5 (h) RSS-GEN, §4.6 Frequency Stability §2.1055 §22.355 RSS-GEN, §4.7 RSS-132, §5.3 §2.1055 §24.235 RSS-GEN, §4.7 RSS-132, §6.3 §2.1055 §27.51 RSS-GEN, §4.7 RSS-139, §6.3 Peak to Average Ration N/A RSS-132, §5.4 §2.1046 §24.232 RSS-133, §6.4 §2.1046 §27.50 (d) RSS-139, §6.4 Modulation Characteristics §2.1047 RSS-132, §5.2 §2.1047 RSS-133, §6.2 §2.1047 RSS-139, §6.2 Field Strength of Spurious Radiation §2.1053 §22.917 RSS-GEN, §4.9 RSS-132, §5.5 §2.1053 §24.235 RSS-GEN, §4.9 RSS-133, §6.5 §2.1053 §27.51 RSS-GEN, §4.9 RSS-139, §6.5 *) Receivers which are part of Transceivers are exempted with respect to Notice 2012-DRS0126. Test report Reference: MDE_UBLOX_1409_FCCb FCC Part 22, Subpart H Page 6 of 47 1 Administrative Data 1.1 Testing Laboratory Company Name: 7Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716 . The test facility is also accredited by the following accreditation organisation: Laboratory accreditation no.: DAkkS D-PL-12140-01-01 Responsible for Accreditation Scope:Dipl.-Ing. Bernhard Retka Dipl.-In g. Robert Machulec Dipl.-Ing. Thomas Hoell Dipl.-Ing. Marco Kullik Dipl.-Ing. Andreas Petz Report Template Version: 2014-09-18 1.2 Project Data Responsible for testing and report: Patrick Lomax Date of Test(s): 2014-07-14 to 2014-09-10 Date of Report: 2014-09-18 1.3 Applicant Data Company Name: u-blox AG Address: Zürcherstrasse 68, CH-8800 Thalwil Switzerland Contact Person: Phone: Email Address: Mr. Giulio Comar +41 44 722 7462 [email protected] 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: MDE_UBLOX_1409_FCCb FCC Part 22, Subpart H Page 7 of 47 2 Test object Data 2.1 General EUT Description Equipment under Test: GSM/UMTS/HSPA/LTE Data Module Type Designation: TOBY-L210 Kind of Device: (optional) Module Voltage Type: DC Voltage Level: 3.8 V T…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Giulio Comar(Certification Manager)

[email protected]+390402529400Fax: +390402529394

Technical Contact

u-bloxGiulio Comar

[email protected]41447227462

Zuercherstrasse 68 · Thalwil · Switzerland

Test Firm

7layers AGRobert Machulec

[email protected]49-2102-749-313Fax: 49-2102-749-350

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
17	27	2.50 GHz - 2.57 GHz	184.50 mW	18M0W7D	0.1 ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Power listed is conducted average. The maximum antenna gain including cable loss for compliance with radiated power limits, RF exposure requirements and the categorical exclusion requirements of 2.1091 is 9.8 dBi for 700 MHz, 4.3 dBi for 850 MHz, 2.8 dBi for 1900 MHz, 5.5 dBi for 1700 MHz and 6.0 dBi for 2500 MHz bands. This transmitter is certified for fixed and mobile installations and the transmitter antenna must be installed to provide a separation distance of at least 20 cm from all persons. The transmitter antenna must not be co-located or operated in conjunction with any other transmitter antenna, except in accordance with FCC multi-transmitter product procedures or as shown in this filing. End users and installers must be provided with instructions to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. territories. This filing is only applicable for 700 MHz MBS, 850 MHz Cell, 1700 MHz AWS, 1900 MHz PCS and 2500 MHz BRS operations. This device has 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 2 and 4; 1.4 MHz, 3 MHz, 5 MHz and 10 MHz bandwidth modes for LTE Band 5; 5 MHz and 10 MHz bandwidth modes for LTE Band 17; and 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Band 7.
