XPYTOBYL280GSM/UMTS/LTE Data Module

TOBY-L2 and MPCI-L2 series LTE/DC-HSPA+/EGPRS modules System Integration Manual Abstract This document describes the features and the system integration of TOBY-L2 and MPCI-L2 series multi-mode cellular modules. These modules are a complete and cost efficient LTE/3G/2G solution offering up to 150 Mb/s download and 50 Mb/s upload data rates, covering up to six LTE bands, up to five WCDMA/DC-HSPA+ bands and four GSM/EGPRS bands in the compact TOBY LGA form factor of TOBY-L2 modules or in the industry standard PCI Express Mini Card form factor of MPCI-L2 modules. TOBY-L2 series www.u-blox.com UBX-13004618 - R08 MPCI-L2 series TOBY-L2 and MPCI-L2 series - System Integration Manual UBX-13004618 - R08 Page 2 of 158 Document Information Title TOBY-L2 and MPCI-L2 series Subtitle LTE/DC-HSPA+/EGPRS modules Document type System Integration Manual Document number UBX-13004618 Revision and date R08 29-Jun-2015 Document status Early Production Information Document status explanation Objective Specification Document contains target values. Revised and supplementary data will be published later. Advance Information Document contains data based on early testing. Revised and supplementary data will be published later. Early Production Information Document contains data from product verification. Revised and supplementary data may be published later. Production Information Document contains the final product specification. This document applies to the following products: Name Type number Modem version Application version PCN / IN TOBY-L200 TOBY-L200-00S-00 09.71 A01.15 UBX-14044437 TOBY-L200-50S-00 09.71 A01.57 UBX-15004131 TOBY-L201 TOBY-L201-01S-00 09.87 A01.01 UBX-15016217 TOBY-L210 TOBY-L210-00S-00 09.71 A01.15 UBX-14044437 TOBY-L210-50S-00 09.71 A01.57 UBX-15004131 TOBY-L280 TOBY-L280-00S-00 09.90 A01.02 UBX-15016802 MPCI-L200 MPCI-L200-00S-00 09.71 A01.15 UBX-14044437 MPCI-L210 MPCI-L210-00S-00 09.71 A01.15 UBX-14044437 u-blox reserves all rights to this document and the information contained herein. Products, names, logos and designs described herein may in whole or in part be subject to intellectual property rights. Reproduction, use, modification or disclosure to third parties of this document or any part thereof without the express permission of u-blox is strictly prohibited. The information contained herein is provided “as is” and u-blox assumes no liability for the use of the information. No warranty, either express or implied, is given, including but not limited, with respect to the accuracy, correctness, reliability and fitness for a particular purpose of the information. This document may be revised by u-blox at any time. For most recent documents, please visit www.u-blox.com. Copyright © 2015, u-blox AG u-blox ® is a registered trademark of u-blox Holding AG in the EU and other countries. PCI, PCI Express, PCIe, and PCI-SIG are trademarks or registered trademarks of PCI-SIG. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. ARM ® is a registered trademark of ARM Limited in the EU and other countries. All other registered trademarks or trademarks mentioned in this document are property of their respective owners. TOBY-L2 and MPCI-L2 series - System Integration Manual UBX-13004618 - R08 Early Production Information Preface Page 3 of 158 Preface u-blox Technical Documentation As part of our commitment to customer support, u-blox maintains an extensive volume of technical documentation for our products. In addition to our product-specific technical data sheets, the following manuals are available to assist u-blox customers in product design and development.  AT Commands Manual: This document provides the description of the AT commands supported by the u-blox cellular modules.  System Integration Manual: This document provides the description of u-blox cellular modules’ system from the hardware and the software point of view, it provides hardware design guidelines for the optimal integration of the cellular modules in the application device and it provides information on how to set up production and final product tests on application devices integrating the cellular modules.  Application Note: These documents provide guidelines and information on specific hardware and/or software topics on u-blox cellular modules. See Related documents for a list of Application Notes related to your Cellular Module. How to use this Manual The TOBY-L2 and MPCI-L2 series System Integration Manual provides the necessary information to successfully design and configure the u-blox cellular modules. This manual has a modular structure. It is not necessary to read it from the beginning to the end. The following symbols are used to highlight important information within the manual: An index finger points out key information pertaining to module integration and performance. A warning symbol indicates actions that could negatively impact or damage the module. Questions If you have any questions about u-blox Cellular Integration:  Read this manual carefully.  Contact our information service on the homepage http://www.u-blox.com/ Technical Support Worldwide Web Our website (http://www.u-blox.com/) is a rich pool of information. Product information, technical documents can be accessed 24h a day. By E-mail Contact the closest Technical Support office by email. Use our service pool email addresses rather than any personal email address of our staff. This makes sure that your request is processed as soon as possible. You will find the contact details at the end of the document. Helpful Information when Contacting Technical Support When contacting Technical Support, have the following information ready:  Module type (TOBY-L200) and firmware version  Module configuration  Clear description of your question or the problem  A short description of the application  Your complete contact details TOBY-L2 and MPCI-L2 series - System Integ…

Text truncated - open the document above for the full version.

Modular Approval Request FCC (per DA 00-1407) FCC ID: XPYTOBYL280 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. Yes 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Yes 3. The modular transmitter must have its own power supply regulation. Yes 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. Yes 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Yes 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Yes 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. Yes 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. Yes Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or Name and surname of applicant (or Name and surname of applicant (or Name and surname of applicant (or authorized authorizedauthorized authorized representative): representative): representative): representative): Imad Hjije Imad HjijeImad Hjije Imad Hjije Date: Date: Date: Date: 06/01/2015 06/01/201506/01/2015 06/01/2015 Signature: Signature: Signature: Signature:

Test Laboratory: 7Layers AG Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H. Ansorge TAX No. 147/5869/0385 www.7Layers.com A Bureau Veritas Group Company Test Report Annex Test Report Reference: Annex to MDE_UBLOX_1510_FCCa on TOBY-L280 GSM/UMTS/HSPA/LTE Data Module FCC ID: XPYTOBYL280 IC:8595A-TOBYL280 Date: July 01, 2015 IC registration number: 3699A-1 TEST REPORT REFERENCE: Annex to MDE_UBLOX_1510_FCCa page 2 of 2 Result applicability The test report MDE_UBLOX_1510_FCCa incorporates results of different variants of a module. The original tests were done on the variant TOBY-L210, test report reference MDE_UBLOX_1409_FCCa. These test results are to be re-used for the new variant TOBY-L280. The test results of the variant TOBY-L280 at the end of test report are only used as justification for the re-use of the original test results. Differences in the new module according to the customer Replaced FDD band 20 with band 28, changes are only related to band 20. Related changes in Hardware: - New PA - New 2 duplexer instead of 1 which are switched by 2 new Switch RF for the high and low band - New filter for the diversity, to support the new band 28

TOBY-L280 Photos and Label u- blox AG Piero Emanuele Laudicina, Apr, 2015 Confidential locate, communicate, accelerate TOBY-L280 Front with shield and Label Placement Slide 2 © u-blox Italia S.p.A., May, 2014 TOBY-L280 without shields Slide 3 © u-blox Italia S.p.A., August, 2013 TOBY-L280 Back Slide 4 © u-blox Italia S.p.A., May, 2014 Thank you! locate, communicate, accelerate

TOBY-L280 Front with shield and Label Placement Slide 2 © u-blox Italia S.p.A., May, 2014

TOBY-L280 Photos and Label u- blox AG Piero Emanuele Laudicina, Apr, 2015 Confidential locate, communicate, accelerate TOBY-L280 Front with shield and Label Placement Slide 2 © u-blox Italia S.p.A., May, 2014 TOBY-L280 without shields Slide 3 © u-blox Italia S.p.A., August, 2013 TOBY-L280 Back Slide 4 © u-blox Italia S.p.A., May, 2014 Thank you! locate, communicate, accelerate

Test Laboratory: 7Layers AG Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H. Ansorge TAX No. 147/5869/0385 www.7Layers.com A Bureau Veritas Group Company RF Exposure and Maximum ERP/EIRP Assessment For TOBY-L280 GSM/UMTS/HSPA/LTE Data Module FCC ID XPYTOBYL280 Assessment Reference: MDE_UBLOX_1510_MPEa rev4 Assessment Reference: MDE_UBLOX_1510_MPEa rev4 Page 2 of 16 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 1 Administrative Data 4 1.1 Testing Laboratory 4 1.2 Project Data 4 1.3 Applicant Data 4 1.4 Manufacturer Data 4 2 Test object Data 5 2.1 General EUT Description 5 2.2 EUT Main components 5 2.3 Ancillary Equipment 5 2.4 Auxiliary Equipment 6 2.5 Operating Modes 7 3 Evaluation Results 8 3.1 Maximum ERP / EIRP 8 3.2 RF Exposure Evaluation for Module 9 3.3 RF Exposure Evaluation for multiple transmitters in co-location 11 Assessment Reference: MDE_UBLOX_1510_MPEa rev4 Page 4 of 16 1 Administrative Data 1.1 Testing Laboratory Company Name: 7Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716. The test facility is also accredited by the following accreditation organisation: Laboratory accreditation no.: DAkkS D-PL-12140-01-01 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Andreas Petz Dipl.-Ing. Marco Kullik Report Template Version: 2014-05-15 1.2 Project Data Responsible for assessment and report: Mr. Andreas Tübel Date of Report: 2015-05-29 1.3 Applicant Data Company Name: u-blox AG Address: Zürcherstrasse 68, CH-8800 Thalwil Switzerland Contact Person: Giulio Comar 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Assessment Reference: MDE_UBLOX_1510_MPEa rev4 Page 5 of 16 2 Test object Data 2.1 General EUT Description Equipment under Test GSM/UMTS/HSPA/LTE Data Module Type Designation: TOBY-L280 Kind of Device: GPRS/EDGE MSC UMTS/LTE Data Module GPRS Multi-slot class 12 FCC ID: XPYTOBYL280 IC Number: 8595A-TOBYL280 General product description: The EUT is Cellular radio module supporting GSM/WCDMA/HSDPA/HSUPA/LTE 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short Description Equipment under Test Type Designation Serial No. HW Status SW Status EUT A (Code: DE1015016aa01) GSM/UMTS LTE Module TOBY-L280 358503060011765 217001 09.90 EUT G (Code: DE1015016ag01) GSM/UMTS LTE Module TOBY-L280 358503060012011 217001 09.90 NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of this test report, ancillary equipment is defined as equipment which is used in conjunction with the EUT to provide operational and control features to the EUT. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Ancillary Equipment can influence the test results. Short Description Equipment under Test Type Designation HW Status SW Status Serial no. FCC ID AE 1 AC/DC converter UUX324- 1215 - - E09- 0291981 – AE 2 Evaluation test board EVB-WL3 NO_EVK_CS _191A00 - - - Assessment Reference: MDE_UBLOX_1510_MPEa rev4 Page 6 of 16 2.4 Auxiliary Equipment For the purposes of this test report, auxiliary equipment is defined as equipment which is used temporarily to enable operational and control features especially used for the tests of the EUT which is not used during normal operation or equipment that is used during the tests in combination with the EUT but is not subject of this test report. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Auxiliary Equipment can influence the test results. Short Description Equipment under Test Type Designation Serial no. HW Status SW Status FCC ID N/A – Assessment Reference: MDE_UBLOX_1510_MPEa rev4 Page 7 of 16 2.5 Operating Modes This chapter describes the operating modes of the EUTs used for testing. Op. Mode Description of Operating Modes Remarks Op-mode 1 EUT transmitting in standalone configuration Antenna-to-person distance > 20cm Op-mode 2 EUT transmitting in the GSM 850 MHz Band simultaneously with a generic Bluetooth radio. Antenna-to-person distance > 20cm Op-mode 3 EUT transmitting in the GSM 1900 MHz Band simultaneously with a generic Bluetooth radio. Antenna-to-person distance > 20cm Op-mode 4 EUT transmitting in the GSM 850 MHz Band simultaneously with a generic WLAN radio. Antenna-to-person distance > 20cm Op-mode 5 EUT transmitting in the GSM 1900 MHz Band simultaneously with a generic WLAN radio. Antenna-to-person distance > 20cm Op-mode 6 EUT transmitting in the GSM 850 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna-to-person distance > 20cm Op-mode 7 EUT transmitting in the GSM 1900 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna-to-person distance > 20cm Op-mode 18 EUT transmitting in the FDD 7 Band simultaneously with a generic Bluetooth radio. Antenna-to-person distance > 20cm Op-mode 19 EUT transmitting in the FDD 7 Band simultaneously with a generic WLAN radio. Antenna-to-person distance > 20cm Op-mode 20 EUT transmitting in the FDD 7 Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna-to-person distance > 20cm Op-mode 21 EUT transmitting in the FDD 5 Band simultaneously with a generic Bluetooth radio. Antenna-to-person distance > 20cm Op-mode 2…
